GE Healthcare
Revision 1
1-39. W213 - POS-Bus 1 between Boards
Rotation Board PL202 J3 to Lift Board PL201 J14.
PIN (PL202)
PL202/J3-1
PL202/J3-2
PL202/J3-3
PL202/J3-4
PL202/J3-5
PL202/J3-6
PL202/J3-7
PL202/J3-8
PL202/J3-9
PL202/J3-10
PL202/J3-11
PL202/J3-12
1-40. W215 - Rotation Optical Fork Connect
Rotation Board PL202 J5 to optical detector S203.
1-41. W216 - Stop Motion Connect (Right)
Emergency Stop R-Button S205 to Interface Board PL104 J6.
1-42. W217 - Stop Motion Connect (Left)
Emergency Stop L-Button S206 to Interface Board PL104 J7.
1-43. W218/221 - Clutch Cables
W218: Clutch B201 to Rotation Board PL202 J8.
W221: Clutch B201 to Rotation Board PL202 J7.
Cables.FM
Designation
H-CAN Network
L-CAN Network
GND
H-RT line 1
L-RT line 1
Stop motion
H-RT line 2
L-RT line 2
Reset line
GND
H-RT line 3
L-RT line 3
Designation
VCC_Led_1
GND
Fork_Opt_Out_1
GND
Service Information and Procedures Class A 2385072-16-8EN
Type
CAN
CAN
Ground
RT-CAN
RT-CAN
RT
RT-CAN
RT-CAN
RT
Ground
RT-CAN
RT-CAN
Type
Level
VCC
5 V
Ground
0 V
Open coll.
0 / +5 V
Ground
0 V
Page no. 307
Cable Lay-out and Pin-out
Level
PIN (PL201)
Diff 5 / 2.5V
PL201/J14-1
Diff 2.5 / 0V
PL201/J14-2
0 V
PL201/J14-3
Diff 5 / 2.5 V
PL201/J14-4
Diff 2.5 / 0V
PL201/J14-5
0/+5 V
PL201/J14-6
Diff 5 / 2.5 V
PL201/J14-7
Diff 2.5 / 0V
PL201/J14-8
0/+5 V
PL201/J14-9
0 V
PL201/J14-10
Diff 5 / 2.5 V
PL201/J14-11
Diff 2.5 / 0V
PL201/J14-12
Pin N°
J5-1
J5-2
J5-3
J5-4
Senographe DS
Chapter 3
