GE Senographe DS Manual page 855

GE Healthcare
Revision 1
Code Category
101/005 DEBUG
ONLY
102/000 HALT
102/001 HALT
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
KEYBOARD FAIL- When pressing a UIF, the IPMS starts a timer on the
URE node concerned by the motion. If the "Start motion"
command is received before the delay has expired,
motion is authorized, otherwise an error is transmit-
ted to Poseidon". Delay is 100 ms. This requirement
does not apply for tilt node and decompression
motion.
Occurs when CPU sends a "Start Motion" to the
node whereas no previous command on CAN
towards the CPU is read by the node before.
1. Try other motions (rotation for example), if the
2. Otherwise, try same lift motion but by pressing
3. Lift, Compression, or Tilt recalibration is
LIFT SOFTWARE The watch-dog receives a pulse from microcontroller
ERROR every 40 ms. If not, it resets the microcontroller,
node restarts and sends a boot-up signal to Gantry
CPU. The only possible reason for a boot-up of a
node after system power-up is a reset by watchdog.
Therefore, when Gantry CPU receives the boot-up
signal, it produces the SWOverRun error.
This failure is linked to a firmware problem (micro-
controller or CPLD). Change the Lift board then per-
form Lift Calibration.
LIFT POSITION There is a Potentiometer defect. Lift node checks
ERROR that the signal coming from the potentiometer is
within an acceptable range.
See
page 946
ERR SUB A003 - Gantry Error Messages
Possible Cause/Recommended Action
button not pressed appears as well, there is a
CAN communication problem.
other buttons than the initial one.
- if the button not pressed appears as well, the
faulty FRU is the Lift board
- if the button not pressed appears only when the
initial Lift button is pressed then the faulty FRU is
the board linked to the UIF that has been
pressed for the motion. For, example the faulty
FRU is the Lift board, Compression board, or
Tube Tilt board.
requested following corresponding board
replacement.
JC DIAG A1004 LIFT CONTROL FAILURE on
to fix the problem.
Page no. 855
Senographe DS
Job Card
D/R A201
page
1161
CAL A031
page
1687
A1004
page 946
Chapter 9
