9-2 Disabling Auto Negotiation and Reducing the Speed of the Network Inter-
face
By default, the Control Station is delivered with auto-negotiation enabled on the network interface
eri0/nge0/e1000g0. Not all hospital switches (or their ports) support auto-negotiation. In the case that the
hospital switch does not support auto-negotiation, you must disable the network interface eri0/nge0/
e1000g0 auto-negotiation capabilities via a command that includes adv_autoneg_cap 0 (see procedures
below).
Once auto-negotiation is disabled, the network interface eri0/nge0/e1000g0 operates at its fasted possi-
ble speed unless you have disabled that speed before disabling the network interface auto-negotiation
capabilities. If the operating speed of the network interface eri0/nge0/e1000g0 remains greater than that
of the hospital switch port which is connected to Control Station, communication with the hospital net-
work may not be possible.
Table 1 summarizes the different network interface speeds, their probability that they work with the hos-
pital switch, and the command used to disable the appropriate speed. If you are disabling auto-negotia-
tion, you must consult the hospital network administrator to determine the maximum speed supported by
the hospital switch port connected to the Control Station. Any speeds that are not supported by the hos-
pital switch port must be disabled on the network interface eri0/nge0/e1000g0 before disabling the auto-
negotiation capabilities.
TABLE 1 - POSSIBLE NETWORK INTERFACE SPEEDS
Network interface
speed
1000 Mbit/s Full Duplex
1000 Mbit/s Half Duplex
100 Mbit/s Full Duplex
100 Mbit/s Half Duplex
10 Mbit/s Full Duplex
10 Mbit/s Half Duplex
JC-ELE-A-021.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A021 - Networking Connection and Configuration
Probability it ndd command used to disable network interface speed
works with
hospital switch
Maybe V1/V2: Not applicable, since 1000 Mbit/s not possible
Maybe V1/V2: Not applicable, since 1000 Mbit/s not possible
Probably V1/V2:
Probably V1/V2:
Usually V1/V2:
Definitely V1/V2:
(via command line or S93route file)
V3:
ndd -set /dev/nge0 adv_1000fdx_cap 0
V4:
ndd -set /dev/e1000g0 adv_1000fdx_cap 0
V3:
ndd -set /dev/nge0 adv_1000hdx_cap 0
V4: Not Applicable - Mode does not exist
ndd -set /dev/eri adv_100fdx_cap 0
V3:
ndd -set /dev/nge0 adv_100fdx_cap 0
V4:
ndd -set /dev/e1000g0 adv_100fdx_cap 0
ndd -set /dev/eri adv_100hdx_cap 0
V3:
ndd -set /dev/nge0 adv_100hdx_cap 0
V4:
ndd -set /dev/e1000g0 adv_100hdx_cap 0
ndd -set /dev/eri adv_10fdx_cap 0
V3:
ndd -set /dev/nge0 adv_10fdx_cap 0
V4:
ndd -set /dev/e1000g0 adv_10fdx_cap 0
ndd -set /dev/eri adv_10hdx_cap 0
V3:
ndd -set /dev/nge0 adv_10hdx_cap 0
V4:
ndd -set /dev/e1000g0 adv_10hdx_cap 0
