GE Senographe DS Manual page 1164

GE Healthcare
Revision 1
Job Card D/R A201 - Lift Board
! Notice:
When reconnecting all the cables to the Lift Board, ensure that you route them so they do not pass
over Lift Board as illustrated in the diagram above. This precaution avoids potential interference
caused by component electronic noise.
Lift Board cable connections.
Connector
Label
J1
J2
J4
J5
J6 If the Senographe system has a Type 1 Lift Screw Assembly (no brake), no
If the Senographe system has a Type 2 Lift Screw Assembly, and has been
fitted with a Top Brake, a black cable with no label, leading up to the Top
If the Senographe system has a Type 3 Lift Screw Assembly, a black cable
with no label, going to the Motor Brake located in the Lift Motor at the bot-
J9
J10
J11
J12
J13
J14
J15
J16
J17
J21
J22
J23
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Description of cable
(usually identified by code on a yellow label)
J1/PL201-W210
J2/PL201-W209
J4/PL201-W201
J5/PL201-W202
cable is attached.
Brake located at the top of the Lift Screw Assembly
tom of the Lift Screw Assembly
J9/PL201 or PL202 - W205
J10/PL201 or PL202 - W206
J11/PL201-W203
J12/PL201-W211
J13/PL201-W208
J14/PL201-W213
Gray ribbon cable to the Gantry digital display
Footwsitch cable with 9 pin D-sub connector
Footwsitch cable with 9 pin D-sub connector
No cable attached
No cable attached
No cable attached
Page no. 1164
Senographe DS
Cable color
Gray
Gray
Gray
Gray
Black (if
brake exists)
Black
Black/Grey
Gray
Gray
Gray
Gray
Gray
N/A
N/A
N/A
N/A
N/A
JC-DR-A-201.fm
