GE Healthcare
Revision 1
8
DECLARE A ROUTER
To declare a router you must create file called S93route in the /etc/rc2.d directory and add some lines
which declare the router. Each time the system boots the information in the /etc/rc2.d/S93route file is
processed automatically and the router is automatically declared. Use the following steps to declare a
router:
1. From behind the Browser, launch a command window (see
page
120).
A command window appears with an ADS prompt.
2. Log in as root as follows:
a. At the ADS prompt enter:
su -
b. When requested to specify the root password, enter:
operator
3. Ensure that the /etc/rc2.d/S93route file exists, by entering:
touch /etc/rc2.d/S93route
4. Allow the /etc/rc2.d/S93route file to be written to, by entering:
chmod ou+w /etc/rc2.d/S93route
5. Exit as root user to return to sdc user, by entering:
exit
You are returned to the command prompt as sdc user.
6. Open the /etc/rc2.d/S93route file with the textedit command, by entering:
textedit /etc/rc2.d/S93route
The /etc/rc2.d/S93route file appears in an X-Windows based TextEdit application window.
7. In the TextEdit application window, type the following four lines (separated by carriage returns):
#!/bin/sh
# Section for routing
echo Starting route service
route add net <network number> <gateway address>
where <network number> is the address to be accessed through the gateway, and <gateway
address> is the IP of the gateway (router) indicated by the administrator.
To calculate the network number (with relation to the network mask) you can use this link to a net-
work/node calculator:
subnet9.html
Note:
Typing the "echo" lines help you to locate any possible faults during boot in case of mistyping the
router information.
8. Save the /etc/rc2.d/S93route file (File > Save) and double click the
TextEdit window to exit the editor.
9. Log in as root as follows:
a. At the ADS prompt enter:
su -
b. When requested to specify the root password, enter:
operator
JC-ELE-A-021.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A021 - Networking Connection and Configuration
http://library.mobrien.com/net.shtml
Page no. 653
Launching a Command Line Window on
or
http://www.subnetonline.com/subcalc/
button in the top left of the
Senographe DS
Chapter 7
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
This answer is automatically generated
