Job Card ELE A050 - Changing Senographe Internal IP Addresses
192.168.100.10) and press the <Return> key.
h. At the gateway inet (g) : 192.168.1.10 prompt, type the new ADS workstation IP address (e.g.
192.168.100.10) and press the <Return> key.
i. At the user (u) : labo prompt, press the <Return> key to retain the current value.
j. At the ftp password (pw) (blank - use rsh) : password prompt, press the <Return> key to
retain the current value.
k. At the flags (f) : 0x0 prompt, press the <Return> key to retain the current value.
l. At the target name (tn) : prompt, press the <Return> key to retain the current value.
m. At the startup scripts (s) : prompt, press the <Return> key to retain the current value.
n. At the other (o) : prompt, press the <Return> key to retain the current value.
The configuration is complete, and you are returned to the > prompt.
Note:
If you make a typing error, you can correct your mistake at the end (in step 20) after re-entering
the command bootChange.
19. At the -> prompt, check that the IP Address changes you made in step 18 above were set by re-
entering:
bootChange
20. Then press the <Return> key at each parameter to and check that the IP addresses have been set
to the correct values.
CAUTION
Double check that the parameters are set as described in step 18 above. An error in any of
the parameters can render the Gantry CPU inoperable, which requires a board replace-
ment.
21. Logout from Poseidon, by entering:
logout
22. Reboot the system (power off and on the Gantry from the X-ray Console).
7-5 Re-enable the External Network
1. From behind the Browser, launch a command window (see
page 120).
A command window appears with an ADS prompt.
2. Re-enable the external network, as follows:
For V1/V2 Control Stations, enter:
ifconfig eri0 up
For V3 Control Stations, enter:
ifconfig nge0 up
For V4 Control Stations, enter:
ifconfig e1000g0 up
7-6 Change the ADS Computer Internal IP Address
Before you undertake the following steps, ensure that you have already undertaken the steps described
