GE Healthcare
Revision 1
DS3
2-9-3.
kVmA Board 700PL1 Switches
Switch
SW1
SW2
2-9-4.
kVmA Board 700PL1 Potentiometer
Switch
P1
P2
P3
P4
P5
Indicators and Switches.fm
- 12 V Present
Service Information and Procedures Class A 2385072-16-8EN
Green
Normal status: ON
ON when the -12 V from the Generator Command
Board 400PL1 is present.
OFF when there is a problem with the -12 V from
the Generator Command Board 400PL1. In this
case, proceed as follows:
• Check the status of the -12 V on the Generator
Command Board 400PL1 indicated by its green
DS11 LED.
If the DS11 LED is ON, change the cable between
the XJ1 connector on the kVmA Board and the
XJ5 connector on the Generator Command
Board 400PL1.
If the DS11 LED is OFF, check whether the -12 V
returns when you disconnect the cable between
the XJ1 connector on the kVmA Board and the
XJ5 connector on the Generator Command Board
400PL1.
If the problem persists (i.e. DS11 is still OFF),
change the Generator Command Board 400PL1.
Function
Test 120 mA
Test 50 mA
Function
kV gain input (1)
kV gain input (2)
Vref B1 adjust
Not Applicable
Measure mA adjust
Page no. 277
Senographe DS
Central Listing
Chapter 3
