GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code
Category
122/031
HALT
122/033
HALT
122/034
WARNING
122/035
HALT
122/036
WARNING
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
COMPRESSION
RELATIVE
ENCODER ERROR
COMRPESSION
COMMAND
SEQUENCE IS
INCORRECT
COMPRESSION
MCU CALIBRA-
TION DATA COR-
RUPT
COMPRESSION
MCU EEPROM
FAILURE
COMPRESSION
CAN COMMAND
NOT PROCESSED
Possible Cause/Recommended Action
The signal coming from the relative encoder does
not evolves during the motion while the signal com-
ing from the absolute encoder does.
Change the Compression Motor + Encoder + Cables
(see
Job Card D/R A244 - Compression Motor with
Encoder and Compression Belt on page 1297
There is a signal command error. The sequence of
the signals to start the motor is wrong.
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
Sensor.
3. Perform a Compression Thickness calibration.
The MCU calibration data is corrupt. The checksum
on the calibration data stored by the MCU does not
match.
1. Perform a calibration of the Compression Force
Sensor.
2. Perform a Compression Thickness calibration.
3. If the problem persists, check the Compression
board cabling.
4. If the problem persists, change the Compression
board.
There is an MCU EEPROM failure. The readback on
the newly written data to the EEPROM is failed.
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
Sensor.
3. Perform a Compression Thickness calibration.
The main CPU have sent command to the compres-
sion node before the compression node could
acknowledge the previous command.
Reboot the system from the X-ray Console.
Retry the command.
If the problem persists, contact your OLC.
Page no. 886
Senographe DS
Job Card
D/R A244
page
1297
).
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
CAL A048
page
1709
CAL A050
page
1721
D/R A250
page
1323
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
ERR-SUB-A-003.fm
