GE Senographe DS Manual page 355

GE Healthcare
Revision 1
10-3-2-2. Anchoring Inserts Not Provided with the Senographe System (for seismic areas)
The following tables provide the recommended anchoring inserts seismic areas. Due to the differing
availability of Hilti bolts in different contentinents, the following tables provide different bolt recommenda-
tions. The minimum floor thickness required varies according to the bolts used.
USA - Hilti Kwick Bolt III
Anchoring holes in the floor
Number of holes in the plate
Diameter of the hole in the
plate
Recommended inserts
Hole diameter in the floor
Hole depth in the floor
Minimum floor thickness
Maximum bolt load pull ten-
sion (at each bolt)
Recommended tightening
torque
EUROPE - Hilti HSA Bolts
Anchoring holes in the floor
Number of holes in the plate
Diameter of the hole in the
plate
Recommended inserts
Hole diameter in the floor
Hole depth in the floor
Maximum bolt load pull ten-
sion (at each bolt)
Minimum floor thickness
Recommended tightening
torque
Chap-Pre-Requirements.fm
Service Information and Procedures Class A 2385072-16-8EN
Gantry baseplate
(see Illustration 15)
3
11 mm
Hilti Kwik Bolt III 3/8"
9.5 mm (3/8")
64 mm (2 ½")
95 mm (3 ¾")
490 daN
34 Nm
Gantry baseplate
(see Illustration 15)
3
11 mm
HSA M10 x 90 - 20 / 25
10 mm
70 mm
490 daN
105 mm
34 Nm
Page no. 355
Pre-Installation System Requirements
Gantry baseplate addi-
tional anchoring holes for
seismic areas
(see Illustration 15)
2
11 mm
Hilti Kwik Bolt III 3/8"
9.5 mm (3/8")
64 mm (2 ½")
95 mm (3 ¾")
490 daN
34 Nm
Gantry baseplate addi-
tional anchoring holes for
seismic areas
(see Illustration 15)
2
11 mm
HSA M10 x 90 - 20 / 25
10 mm
70 mm
490 daN
105 mm
34 Nm
Senographe DS
Control station base-
plate
(see Illustration 16)
4
14 mm
Hilti Kwik Bolt III 3/8"
9.5 mm (3/8")
64 mm (2 ½")
95 mm (3 ¾")
490 daN
34 Nm
Control station base-
plate
(see Illustration 16)
4
14 mm
HSA M10 x 90 - 20 / 25
10 mm
70 mm
490 daN
105 mm
34 Nm
Chapter 4
