Technical Publication
Ultrasound System
Common Service Information
Direction Number: Direction 5444964-100 English
Rev. 5
BASIC SERVICE DOCUMENTATION.
COPYRIGHT GENERAL ELECTRIC COMPANY.
© 2013-2018 General Electric Company. All Rights Reserved.

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for GE LOGIC C2 Series

  • Page 1 Technical Publication Ultrasound System Common Service Information Direction Number: Direction 5444964-100 English Rev. 5 BASIC SERVICE DOCUMENTATION. COPYRIGHT GENERAL ELECTRIC COMPANY. © 2013-2018 General Electric Company. All Rights Reserved.
  • Page 2 © 2013-2018 General Electric Company. Manufacturer: GE Medical Systems www.gehealthcare.com...
  • Page 3 Data Management). If you need to know the latest revision, contact your distributor, local GE Sales Representative, or in the USA call the GE Ultrasound Clinical Answer Center at 1 800 682 5327 or 1 262 524 5698. Note: Testing requirements and descriptions of the safety equipment in this Common Service Information (CSI) Manual supersedes the product’s Service Manual if that manual’s publication date precedes the date of this CSI...
  • Page 4 Important precautions – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 5 Translation policy – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 6 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 7 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 8 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 9 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 10 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 11 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 12 i-10 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 13 – i-11 Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 14 i-12 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 15 – i-13 Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 16 “Damage in Shipment” on ALL copies of the freight or express bill BEFORE delivery is accepted or “signed for” by a GE representative or hospital receiving agent. Whether noted or concealed, damage MUST be reported to the...
  • Page 17 GE personnel. In performing all electrical work on these products, GE will use its own specially trained field engineers. All of GE’s electrical work on these products will comply with the requirements of the applicable electrical codes.
  • Page 18 Omission and errors If there are any omissions, errors or suggestions for improving this documentation, contact the GE Ultrasound Global Documentation Group with specific information listing the system type, manual title, part number or direction number, revision number, page number and suggestion details.
  • Page 19 GE. GE makes no representations or warranties with respect to the information herein. In addition, the information is subject to change without notice. Every precaution has been taken in the preparation of this document.
  • Page 20 i-18 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 21: Table Of Contents

    Table of Contents Translation policy - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i-3 Damage in transportation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i-14 Certified electrical contractor statement - For USA Only - - - - - - - - - - - - i-15 Omission and errors - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i-16...
  • Page 22 Electromagnetic compatibility (EMC) What is EMC? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-22 Compliance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-22 Electrostatic discharge (ESD) prevention - - - - - - - - - - - - - - - - - - - - - 2-23 Chapter 3 —...
  • Page 23 Isolated patient lead (source) leakage–lead to lead - - - - - - - - - - - - - - 4-31 Isolated patient lead (sink) leakage-isolation test - - - - - - - - - - - - - - - - 4-33 Probe (Source) leakage current test - - - - - - - - - - - - - - - - - - - - - - - - - 4-35 Isolated Probe (Sink) Leakage-Isolation Test- - - - - - - - - - - - - - - - - - - 4-40 When there's too much leakage current …...
  • Page 24 i-22 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 25: Chapter 1 - Overview

    Chapter 1 Overview This Service Manual includes common service information for GE’s Ultrasound systems. The manual provides Installation, Safety, and Maintenance information. – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 26: Content In This Manual

    Overview Content in this manual The following topics are covered in this manual: • Products covered in this manual. See Chapter 1 (this chapter). • Safety Information. See Chapter 2. • Site Preparations. See Chapter 3. • Care and Maintenance. See Chapter 4. –...
  • Page 27: Product Description

    Product description Product description Overview of the Ultrasound System This Ultrasound System is a high performance digital ultrasound imaging system with total data management. The fully digital architecture of the Ultrasound System allows optimal usage of all scanning modes and probe types throughout the full spectrum of operating frequencies.
  • Page 28: Products Covered In This Manual

    Overview Products Covered in this Manual This Common Service Information (CSI) Manual is effective for the products listed in Table 1-1. Testing requirements and descriptions of the safety equipment in this Common Service Information (CSI) Manual supersedes the product’s Service Manual if that manual’s publication date is earlier than the date of this CSI manual.
  • Page 29: Chapter 2 - Safety Information

    Chapter 2 Safety Information This chapter describes important issues related to safely servicing the Ultrasound System. The service provider must read and understand all the information presented here before installing or servicing the Ultrasound System. – Ultrasound System Common Service Information Direction 5444964-100 English Rev.
  • Page 30: Overview

    Safety Information Overview Contents in this chapter • ‘Important conventions’ on page 2-3 • ‘Product Icons’ on page 2-7 • ‘Safety considerations’ on page 2-8 • ‘Label locations’ on page 2-18 • ‘Dangerous procedure warnings’ on page 2-19 • ‘Lockout/Tagout (LOTO)’ on page 2-20 •...
  • Page 31: Important Conventions

    Important conventions Important conventions Conventions used in book Important conventions, used in this document, are described below. Icons Pictures, or icons, are used wherever they will reinforce the printed message. The icons, labels, and conventions used on the product and in the service information are described in this chapter.
  • Page 32 Safety Information Important conventions (continued) Safety precaution messages Various levels of safety precaution messages may be found on the equipment and in the service information. The different levels of concern are identified by a flag word that precedes the precautionary message. Known or potential hazards to personnel are labeled in one of three ways: •...
  • Page 33: Standard Hazard Icons

    Important conventions Standard hazard icons Important information will always be preceded by either the exclamation point (!) contained within a triangle, or the symbols for “Danger”, “Warning” or “Caution”, as seen throughout this chapter and manual. In addition to text, several different graphical icons (symbols) may be used to make you aware of specific types of hazards that could possibly cause harm.
  • Page 34 Safety Information Standard Icons that indicate that a special procedure is to be used Other icons make you aware of specific procedures that should be followed. Table 2-2: Standard Icons that indicates that a special procedure is to be used Avoid Static Electricity Tag and Lock Out Wear Eye Protection...
  • Page 35: Product Icons

    Product Icons Product Icons Label Icon Description Refer to the User’s Manual for a description and location of Ultrasound System icons. How to lock the Operator Panel prior to transport Refer to the User Manual for the Ultrasound console for instructions.
  • Page 36: Safety Considerations

    Safety Information Safety considerations Introduction The following safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the equipment.
  • Page 37 Because of the limited access to cabinets and equipment in the WARNING field, placing people in awkward positions, GE has limited the lifting weight for one person in the field to 16 KG (35 LBS). Anything over 16 KG (35 LBS) requires 2 people.
  • Page 38 Safety Information Human Safety (continued) Risk of electrical shock, Ultrasound system must be turned off WARNING and disconnected from power source. Cord must be controlled at all times. Wait for at least 30 seconds for capacitors to discharge as there are no test points to verify isolation. The light on the OP panel on/off button will turn off.
  • Page 39: Mechanical Safety

    Safety considerations Mechanical safety Ultrasound probes are highly sensitive medical instruments WARNING that can easily be damaged by improper handling. Use care when handling and protect from damage when not in use. Do not use a damaged or defective probe. Failure to follow these precautions can result in serious injury and equipment damage.
  • Page 40 Safety Information Mechanical safety (continued) Ultrasound System weights can be significant, plus the weight CAUTION of installed peripherals, when ready for use. Care must be used when moving it or replacing its parts. Failure to follow the precautions listed below could result in injury, uncontrolled motion and costly damage.
  • Page 41 Safety considerations Mechanical safety (continued) Use safety shoes when doing work where there is any chance CAUTION of foot injury. Be careful not to pinch any of the cables. CAUTION – 2-13 Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 42 Safety Information Console Ultrasound System Prior to elevating Ultrasound system: WARNING • verify that the floating Operating Panel is locked in its lowest, parking position. • verify that the front brake is locked and the Ultrasound system is unable to swivel. •...
  • Page 43 Safety considerations Console Ultrasound System (continued) Before you move or transport the Ultrasound system, make CAUTION sure to lock the LCD monitor arm firmly and flip down the monitor to prevent damage to the Ultrasound system. Always lock the Top Console (Operating Panel) in its parking CAUTION (locked) position before moving the Ultrasound system around.
  • Page 44: Electrical Safety

    Safety Information Mechanical safety (continued) NOTE: Special care should be taken when transporting the Ultrasound system in a vehicle: • Before transporting, place the Ultrasound system in its special storage case. • Ensure that the Ultrasound system is firmly secured while inside the vehicle.
  • Page 45 Safety considerations Probes Follow these guidelines before connecting a probe to the Ultrasound system: • Inspect the probe prior to each use for damage or degradation to the: • housing • cable strain relief • lens • seal • connector pins •...
  • Page 46: Label Locations

    Safety Information Label locations Product Labels It is important to refer to the current revision of the Ultrasound System’s User Manual for a full list of product labels prior to servicing the Ultrasound System. 2-18 – Ultrasound System Common Service Information Direction 5444964-100 English Rev.
  • Page 47: Dangerous Procedure Warnings

    Operation of any electrical equipment in such an environment constitutes a definite safety hazard. DO NOT substitute parts or modify equipment WARNING Because of the danger of introducing additional hazards, ONLY install GE approved parts. DO NOT perform any unauthorized modification of the equipment. – 2-19 Ultrasound System Common Service Information Direction 5444964-100 English Rev.
  • Page 48: Lockout/Tagout (Loto)

    Safety Information Lockout/Tagout (LOTO) LOTO Requirements Follow Lockout/Tagout requirements by ensuring you are in total control of the AC power plug at all times during the service process. To apply Lockout/Tagout (LOTO): 1. Plan and prepare for shutdown. 2. Shutdown the equipment. 3.
  • Page 49: Returning Probes And Repair Parts

    Equipment being returned must be clean and free of blood and other infectious substances. GE policy states that body fluids must be properly removed from any part or equipment prior to shipment. GE employees, as well as customers, are responsible for ensuring that parts/equipment have been properly decontaminated prior to shipment.
  • Page 50: Electromagnetic Compatibility (Emc)

    Safety Information Electromagnetic compatibility (EMC) What is EMC? Electromagnetic compatibility describes a level of performance of a device within its electromagnetic environment. This environment consists of the device itself and its surroundings including other equipment, power sources and persons with which the device must interface.
  • Page 51: Electrostatic Discharge (Esd) Prevention

    Electromagnetic compatibility (EMC) Electrostatic discharge (ESD) prevention DO NOT touch any boards with integrated circuits prior to WARNING taking the necessary ESD precautions. Always connect yourself, via an arm-wrist strap, to the advised ESD connection point located on the rear of the Ultrasound system (near the power connector).
  • Page 52 Safety Information 2-24 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 53: Chapter 3 - Site Preparations

    Chapter 3 Site Preparations This chapter provides the information required to plan and prepare for the setup of an Ultrasound system. Included are descriptions of the facility and electrical needs to be met by the purchaser of the Ultrasound system. –...
  • Page 54: Overview

    Site Preparations Overview Contents in this chapter • ‘General Ultrasound system requirements’ on page 3-3 • ‘Facility needs’ on page 3-21 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 55: General Ultrasound System Requirements

    General Ultrasound system requirements General Ultrasound system requirements Contents in this section • ‘Ultrasound system environmental requirements’ on page 3-3 • ‘Electrical requirements’ on page 3-5 • ‘EMI limitations’ on page 3-18 • ‘EMI prevention/abatement’ on page 3-19 • ‘Probes environmental requirements’ on page 3-20 •...
  • Page 56 Site Preparations Environmental specifications for Ultrasound System system Refer to the User Manual/ Basic User Manual for the product. Cooling The cooling requirement for a console Ultrasound system with monitor and on board peripherals, is up to 3800 BTU/h. This figure does not include cooling needed for lights, people, or other equipment in the room.
  • Page 57: Electrical Requirements

    General Ultrasound system requirements Electrical requirements General requirements NOTE: GE requires a dedicated power and ground for the proper operation of its Ultrasound equipment. This dedicated power shall originate at the last distribution panel before the Ultrasound system. The Ultrasound System will function on voltages from 100-240 Volts and 50 or 60 Hz.
  • Page 58 Site Preparations Electrical requirements for Console Ultrasound Systems Contents: • ‘Electrical Requirements - Invenia ABUS’ on page 3-6 • ‘Electrical requirements - LOGIQ Consoles’ on page 3-7 • ‘Electrical Specifications for LOGIQ C Series and LOGIQ C3/C5 Premium’ on page 3-8 •...
  • Page 59 General Ultrasound system requirements Table 3-3: Electrical requirements - LOGIQ Consoles Current or Power Product Voltage Tolerance Consumption Frequency LOGIQ E10 100-240 VAC 0.9kVA LOGIQ E9 100-240 VAC 1100 W (valid through R5) 1.0kVA (effective from R6) LOGIQ P5 100-120 VAC 750 VA LOGIQ A5 200-240 VAC...
  • Page 60 Site Preparations Electrical requirements for Console Ultrasound Systems (continued) The following power line parameters should be monitored for one week before installation. We recommend that you use an analyzer Dranetz Model 606-3 or Dranetz Model 626: Table 3-4: Electrical Specifications for LOGIQ C Series and LOGIQ C3/C5 Premium Parameter Area Limits...
  • Page 61 General Ultrasound system requirements Electrical requirements for Console Ultrasound Systems (continued) Table 3-5: Electrical Requirements - Vivid Consoles Current or Power Product Voltage Tolerance Consumption Frequency Vivid E7/E9 100-230 VAC 1100 W Vivid 7 230 VAC Vivid 7 100-120 VAC 10 A Vivid S5/S5N 100-240 VAC...
  • Page 62 Site Preparations Electrical requirements for Console Ultrasound Systems (continued) Table 3-6: Electrical Requirements - Voluson Consoles Current or Power Product Voltage Tolerance Consumption Frequency 100 VAC 10.1 A 110 VAC 9.2 A Voluson® 730 115 VAC 8.8 A 130 VAC 7.8 A ±10% 50, 60 Hz (±2Hz)
  • Page 63 Power Product Voltage Tolerance Consumption Frequency LBAC-66 adapter for 120 VA 1.2-0.5 A LOGIQ Book GE-90W adapter for 50-60 Hz LOGIQ Book 108 VA 1.08-0.45 ADM-9020M-GE for 100-240 VAC ±10% LOGIQ Book XP Series Adapter for LOGIQ e and LOGIQ e Vet R7.x.x and 130 VA max.
  • Page 64 Site Preparations Electrical requirements for Laptop Ultrasound Systems (continued) Table 3-8: Electrical Requirements - Vivid Laptops Current or Power Product Voltage Tolerance Consumption Frequency AC/DC Converter for Vivid i/Vivid iN and 100 - 240 VAC ±10% 0.5 to 1.0 A 50-60 Hz Vivid q/ Vivid qN Adapter for Vivid e...
  • Page 65 General Ultrasound system requirements Electrical Requirements for Docking Carts Table 3-10: Docking Cart for LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid| e/Vivid iq Power Requirements PARAMETER AREA LIMITS FREQUENCY Voltage Range (Docking Cart used for LOGIQ e/ 100-120V~ 500VA LOGIQ e Vet R7.x.x and 220-240V~ 500VA below, LOGIQ i and Vivid...
  • Page 66 Site Preparations Electrical Requirements for Isolation Cart Table 3-11: Isolation Cart for LOGIQBook XP Series/LOGIQ e/LOGIQ e Vet/LOGIQ i/ Vivid e Input Output 100-120V~, 50/60Hz, 500VA 100-120V~, 50/60Hz, 250VA 220-240V~, 50/60Hz, 500VA 220--240V~, 50/60Hz, 250VA Table 3-12: E-Isolation Cart for LOGIQ e Input Output 100-120V~, 60Hz, 400VA...
  • Page 67 General Ultrasound system requirements Electrical requirements for the Handheld Ultrasound Systems Contents: • ‘Electrical Requirements - Venue Series’ on page 3-15 Table 3-14: Electrical Requirements - Venue Series Current or Power Product Voltage Tolerance Consumption Frequency Venue 500 VA Venue 40/50 180 VA max.
  • Page 68 Site Preparations Electrical requirements for the Ultrasound workstations Contents: • ‘Electrical Requirements - EchoPAC PC Turnkey Workstations’ on page 3-16 • ‘Electrical Requirements - LOGIQworks Workstations’ on page 3-16 Table 3-15: Electrical Requirements - EchoPAC PC Turnkey Workstations Current or Power Product Voltage...
  • Page 69 Electrical installation must meet all current local, state, and national electrical codes. Power cable If the Ultrasound system arrives without a power cable, or with the wrong cable, you must contact your GE dealer or the installation engineer must supply what is locally required. – 3-17...
  • Page 70: Emi Limitations

    Site Preparations EMI limitations Ultrasound systems are susceptible to Electromagnetic Interference (EMI) from radio frequencies, magnetic fields, and transients in the air or wiring. They also generate EMI. The Ultrasound system complies with limits as stated on the EMC label. However, there is no guarantee that interference will not occur in an installation.
  • Page 71 Frequency leakage. Or, if a label has been found in such a position, move the label. Use GE specified The interconnect cables are grounded and require ferrite beads and other harnesses and peripherals shielding. Also, cable length, material, and routing are all important; do not change from what is specified.
  • Page 72: Probes Environmental Requirements

    Site Preparations Probes environmental requirements Operation and storage temperatures for probes For probe operation and storage temperature information, refer the the Ultrasound System or Probe User Manual. Time and manpower requirements Site preparation takes time. Begin site preparation checks as soon as possible, if possible, six weeks before delivery, to allow enough time to make any changes.
  • Page 73: Facility Needs

    Facility needs Facility needs Contents in this section • ‘Purchaser responsibilities’ on page 3-21 • ‘Required facility needs’ on page 3-23 • ‘Desirable features’ on page 3-25 Purchaser responsibilities The work and materials needed to prepare the site is the responsibility of the purchaser.
  • Page 74 All electrical work on these products must comply with the requirements of applicable electrical codes. The purchaser of GE equipment must only utilize qualified personnel to perform electrical servicing on the equipment. The desire to use a non–listed or customer provided product or...
  • Page 75: Required Facility Needs

    Facility needs Required facility needs NOTE: GE requires a dedicated power and ground for the proper operation of its Ultrasound equipment. This dedicated power shall originate at the last distribution panel before the Ultrasound system. The Ultrasound system will function on voltages from 100-240 Volts and 50 or 60 Hz.
  • Page 76 Site Preparations Required facility needs (continued) Scale: Each square equal one square foot (app. 31 x 31 cm) 1. Secretaries or Doctors Desk 8. Suction Line 14. Footswitch 2. File Cabinet 9. Ultrasound system 15. Storage for Linens and 3. Film Viewer 10.
  • Page 77: Desirable Features

    Storage for linens and equipment • Nearby waiting room, lavatory, and dressing room • Dual level lighting (bright and dim) • Lockable cabinet ordered by GE for its software and proprietary manuals – 3-25 Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 78 Site Preparations 3-26 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 79: Care And Maintenance

    Chapter 4 Care and Maintenance This chapter describes Care and Maintenance on the Ultrasound system and peripherals. These procedures are intended to maintain the quality of the Ultrasound system’s performance. Read this chapter completely and familiarize yourself with the procedures before performing a task.
  • Page 80: Contents In This Chapter

    Care and Maintenance Overview Care and Maintenance Normal Care and Maintenance is mandatory; it is the responsibility of the customer and includes the following: • Quality Assurance Program to perform routine quality control testing. NOTE: Some customers’ Quality Assurance Programs may require additional tasks and or inspections at a different frequency than listed in this manual.
  • Page 81: Warnings

    CAUTION and frame panels are securely in place. System performance and cooling require this. To ensure the mutual protection and safety of GE service CAUTION personnel and our customers, all equipment and work areas must be clean and free of any hazardous contaminants before a Service Engineer starts a repair.
  • Page 82: Why Do Maintenance

    Testing results, corrective action and the effects of corrective action must be documented and maintained on the site. Your GE service representative can help you with establishing, performing and maintaining records for a quality assurance program. Contact GE for coverage and/or price for service.
  • Page 83: Maintenance Task Schedule

    System care and maintenance is performed as scheduled in order to retain its high level of safety, dependability and performance. Your GE Service Representative has an in-depth knowledge of your Ultrasound System and can best provide competent, efficient service. Contact GE for coverage information and/or price for service.
  • Page 84: System Maintenance

    Care and Maintenance System maintenance Preliminary checks The preliminary checks take about 15 minutes to perform. Refer to the Ultrasound system user documentation whenever necessary. Table 4-1: Ultrasound system preliminary checks Step Item Description Ask and Listen Ask the customer if they have any problems or questions about the equipment.
  • Page 85: Functional Checks

    System maintenance Functional checks The functional checks take about 60 minutes to perform. Refer to the Ultrasound system user documentation whenever necessary. System checks Table 4-2: Ultrasound system functional checks Step Item Description B-Mode Verify basic B-Mode (2D) operation. Check the basic Ultrasound system controls that affect this mode of operation.
  • Page 86 Care and Maintenance Peripheral/option checks If any peripherals or options are not part of the Ultrasound system configuration, the check can be omitted. Table 4-3: GE approved peripheral/hardware option functional checks Step Item Description Media Verify media drive(s) read/write properly. Clean if necessary.
  • Page 87: Physical Inspection

    System maintenance Optional diagnostic checks To complete the Ultrasound System checks, view the error logs and run desired diagnostics. View the logs 1. Review the Ultrasound system error log for any problems. 2. Check the temperature log to see if there are any trends that could cause problems in the future.
  • Page 88 Care and Maintenance Table 4-5: Physical checks (Continued) Step Item Description Wheels and • Where applicable, check all wheels and casters for wear and verify Brakes operation of foot brake, to stop the Ultrasound system from moving, and release mechanism. •...
  • Page 89: Cleaning

    System maintenance Cleaning Refer to the User Manual for the Ultrasound console for instructions. Air filter cleaning Refer to the User Manual for the Ultrasound console for instructions. – 4-11 Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 90: Probe Maintenance

    GE website at http://www3.gehealthcare.com/en/Products/ Categories/Ultrasound/Ultrasound_Probes. DO NOT use non-GE-approved disinfectants or products that have not been evaluated by GE for material compatibility. Damages linked to the use of disapproved chemicals are not covered under product warranty or service contract.) 4-12 –...
  • Page 91: Using A Phantom

    Using a Phantom Using a Phantom Phantoms The use of a Phantom is not required during Care and Maintenance, except for the Invenia ABUS Scan Station. Customer may use it as part of their Quality Assurance Program tests. – 4-13 Ultrasound System Common Service Information Direction 5444964-100 English Rev.
  • Page 92: Electrical Safety Tests

    Care and Maintenance Electrical safety tests Content in this section The following topics and measurements are covered in this section: • ‘Uninterrupted Power Supply (UPS)’ on page 4-15 • ‘Safety test overview’ on page 4-16 • ‘Leakage current limits’ on page 4-19 •...
  • Page 93: Uninterrupted Power Supply (Ups)

    Electrical safety tests Uninterrupted Power Supply (UPS) NOTE: For all instructions in the “Electrical safety tests” section in case of using a UPS (uninterrupted power supply) the terms outlet, wall outlet, AC wall outlet and power outlet refer to the AC power outlet of the UPS.
  • Page 94: Safety Test Overview

    Care and Maintenance Safety test overview Energy Control and Power Lockout for Ultrasound System. WARNING When servicing parts of the Ultrasound system where there is exposure to voltage greater than 30 volts: 1. Follow LOCK OUT/TAG OUT procedures. 2. Turn off the breaker. 3.
  • Page 95 Electrical safety tests Safety test overview (continued) Prior to initiating any electrical test, the Ultrasound system must be visually inspected. Perform the following visual checks: • Check for missing or loose enclosure covers that could allow access to internal live parts. •...
  • Page 96 Compare all safety-test results with safety-test results of CAUTION previously performed safety tests (e.g. last year etc). In case of unexplainable abrupt changes of safety-test results consult experienced authorized service personnel or GE for further analysis. To avoid electrical shock, the Ultrasound system under test CAUTION MUST NOT be connected to other electrical equipment.
  • Page 97: Leakage Current Limits

    Electrical safety tests Leakage current limits Energy Control and Power Lockout for Ultrasound System. WARNING When servicing parts of the Ultrasound system where there is exposure to voltage greater than 30 volts: 1. Follow LOCK OUT/TAG OUT procedures. 2. Turn off the breaker. 3.
  • Page 98 Care and Maintenance LOGIQ/Vivid/Voluson Ultrasound System Leakage Current Limits Leakage current limits for LOGIQ, Vivid and VOLUSON Ultrasound Systems are shown below for 100-130 Volt and 220-240 Volt mains. Table 4-6: Leakage current limits for Ultrasound system operation on 100-130 Volt mains (US/Canada/Japan) System Grounding/...
  • Page 99 Electrical safety tests LOGIQ/Vivid/Voluson Ultrasound System Leakage Current Limits (continued) Table 4-7: Leakage current limits for Ultrasound system operation on 220-240 Volt mains System Grounding/ Limit in Limit in Leakage Current Test Power PE Conductor µA Earth Leakage On and Off Chassis/Enclosure Leakage On and Off Closed...
  • Page 100 Care and Maintenance LOGIQ/Vivid/Voluson Ultrasound System Leakage Current Limits (continued) NOTE: Electrical leakage testing may be accomplished with any calibrated Electrical Safety Analyzer tool compliant with AAMI/ ESI 1993 or IEC 60601 or AS/NZS 3551 or IEC62353 or other relevant national regulation. Table 4-9: Equipment Type and Test Definitions Applied Parts...
  • Page 101: Outlet Test - Wiring Arrangement - Usa And Canada

    Electrical safety tests Outlet test - wiring arrangement - USA and Canada Test all outlets in the area for proper grounding and wiring arrangement by plugging in the neon outlet tester and noting the combination of lights that are illuminated. Any problems found should be reported to the hospital immediately and the receptacle should not be used.
  • Page 102: Grounding Continuity

    Care and Maintenance Grounding continuity DANGER Electric Shock Hazard! The patient or operator MUST NOT come into contact with the equipment during this test. Measure the resistance from the third pin of the attachment plug to the exposed metal parts of the case. The ground wire resistance should be less than 0.2 ohms.
  • Page 103: Chassis Leakage Current Test

    Electrical safety tests Chassis leakage current test DANGER Electric Shock Hazard. When the Electrical Safety Analyzer's ground switch is OPEN, DO NOT touch the Ultrasound system! Equipment damage possibility. CAUTION Never switch the Polarity and the status of Neutral when the Ultrasound system is powered ON.
  • Page 104 Care and Maintenance Generic procedure The test verifies the isolation of the power line from the chassis. The testing Electrical Safety Analyzer is connected from accessible metal parts of the case to ground. Measurements should be made under the test conditions specified in: •...
  • Page 105 Electrical safety tests Data sheet for enclosure/chassis leakage current Table 4-10 shows a typical format for recording the enclosure/ chassis leakage current. Measurements should be recorded from multiple locations for each set of test conditions. The actual location of the test probe may vary by Ultrasound system. Record all data in the Electrical safety tests log.
  • Page 106 Care and Maintenance Table 4-11: Typical data format for recording enclosure/chassis leakage (Continued) Unit under test____________________________________ Date of test:_____________ Test Conditions Measurement/Test Point Location Potential System Grounding/ Limit equilibrium Monitor Probe Power µA connector housing connector open (reversed polarity) closed (reversed polarity) open (reversed...
  • Page 107: Isolated Patient Lead (Source) Leakage-Lead To Ground

    Electrical safety tests Isolated patient lead (source) leakage–lead to ground Equipment damage possibility. CAUTION Never switch the Polarity and the status of Neutral when the Ultrasound system is powered ON. Power off the Ultrasound system, allow the stored energy to bleed down, and turn the circuit breaker off BEFORE switching the "POLARITY"...
  • Page 108 Care and Maintenance Generic procedure 1. Connect the Safety analyzer to wall AC power outlet. 2. Plug the equipment under test power cable into the receptacle on the panel of the Electrical Safety Analyzer. 3. Connect the ECG cable to the Ultrasound system and the patient leads to the analyzer.
  • Page 109: Isolated Patient Lead (Source) Leakage-Lead To Lead

    Electrical safety tests Isolated patient lead (source) leakage–lead to lead Select and test each of the ECG lead positions (except ALL) on the LEAD selector, testing each to the power and ground condition combinations found in: • Table 4-6 on page 4-20, or: •...
  • Page 110 Care and Maintenance Lead to lead leakage test record (continued) NOTE: Not all test procedures are applicable to all areas of the world. Reversed Polarity testing content satisfies regions following IEC 62353:2007 and IEC 60601-1:2005. Table 4-12: Typical data format for recording patient lead to lead leakage Unit under test____________________________________ Date of test:_____________ Test Conditions...
  • Page 111: Isolated Patient Lead (Sink) Leakage-Isolation Test

    Electrical safety tests Isolated patient lead (sink) leakage-isolation test Select the Individual Leads as well as All Lead position since the test is performed with mains applied to all ECG leads at the same time. Line voltage is applied to the ECG leads during this test. To CAUTION avoid possible electric shock hazard, the Ultrasound system being tested must not be touched by patients, users or anyone...
  • Page 112 Care and Maintenance Isolated lead (sink) leakage test record (continued) Keep a record of the results with other hard copies of maintenance data using Table 4-14. NOTE: Not all test procedures are applicable to all areas of the world. Reversed Polarity testing content satisfies regions following IEC 62353:2007 and IEC 60601-1:2005.
  • Page 113: Probe (Source) Leakage Current Test

    Electrical safety tests Probe (Source) leakage current test Do not use the probe if the insulating material has been WARNING punctured or otherwise compromised. Integrity of the insulation material and patient safety can be verified by safety testing according to IEC60601-1. Definition This test measures the current that would flow to ground from any of the probes through a patient who is being scanned and...
  • Page 114 Care and Maintenance Generic procedure on probe leakage current The most common method of measuring probe leakage is to partly immerse the probe into a saline bath while the probe is connected to the Ultrasound system and active. This method measures the actual leakage current resulting from the probe RF drive.
  • Page 115 Electrical safety tests Generic procedure on probe leakage current (continued) NOTE: Each probe will have some amount of leakage, dependent on its design. Small variations in probe leakage currents are normal from probe to probe. Other variations will result from differences in line voltage and test lead placement.
  • Page 116 Care and Maintenance Generic procedure on probe leakage current (continued) 9. Test opening and closing the ground with the Ultrasound system on and off. a. Power ON the Ultrasound system. b. After the Ultrasound system has completed the boot process, select the probe to be tested so it is the active probe.
  • Page 117 Electrical safety tests Generic procedure on probe leakage current (continued) NOTE: Not all test procedures are applicable to all areas of the world. Reversed Polarity testing content satisfies regions following IEC 62353:2007 and IEC 60601-1:2005. Table 4-16: Typical data format for recording probe (source) leakage current Unit under test___________________________ Date of test:___________ Test Conditions...
  • Page 118: Isolated Probe (Sink) Leakage-Isolation Test

    Care and Maintenance Isolated Probe (Sink) Leakage-Isolation Test Do not use the probe if the insulating material has been WARNING punctured or otherwise compromised. Integrity of the insulation material and patient safety can be verified by safety testing according to IEC60601-1. Line voltage is applied to the ultrasound probe during this test.
  • Page 119 Electrical safety tests Isolated Probe (Sink) Leakage-Isolation Test (continued) Record all data and keep the record of the result with other hard copies of maintenance data. NOTE: Not all test procedures are applicable to all areas of the world. Reversed Polarity testing content satisfies regions following IEC 62353:2007 and IEC 60601-1:2005.
  • Page 120 TEE and Trans thorax probes bearing the symbol for safety class BF. The symbol for BF is indicated on the probe connector label below: Figure 4-5. GE Probe Connector Label example 4-42 – Ultrasound System Common Service Information Direction 5444964-100 English Rev.
  • Page 121 Electrical safety tests Mains on applied part (continued) A typical test setup for TEE probes could be as indicated below: Figure 4-6. TEE probe leakage isolation (sink) current test The handle of the TEE probes must not be immersed. WARNING For immersion levels, please refer to the User Manual.
  • Page 122: When There's Too Much Leakage Current

    Care and Maintenance When there's too much leakage current … AC/DC Fails Where applicable, check the AC/DC adapter and its cable. Replace a new one if any portion is defective. Chassis Fails Check the ground on the power cord and plug for continuity. Ensure the ground is not broken, frayed, or intermittent.
  • Page 123: Probe Fails

    When there's too much leakage current … Probe Fails Test the probe in another connector to isolate if the fault lies with the probe or the Ultrasound system. NOTE: Each probe will have some amount of leakage, dependent on its design.
  • Page 124: Ultrasound Equipment Quality Check (Eqc And Iqc)

    Care and Maintenance Ultrasound Equipment Quality Check (EQC and IQC) Quality Checks Contact your GE Service Representative to perform Equipment and Image Quality Checks. 4-46 – Ultrasound System Common Service Information Direction 5444964-100 English Rev. 5...
  • Page 125 Index what is EMC?, 2-22 abatement, 3-19 acclimate time, 3-3 prevention, 3-19 EMI limitations, 3-18 environmental requirements, 3-3 before installation (site preparations), 3-1 environmental specifications for ultrasound system, 3-4 ultrasound equipment quality check, 4-46 cable inspection errors, i-16 mains cable inspection, 4-8 ESD prevention, 2-23 Care and Maintenance, 4-2 care and maintenance, 4-1...
  • Page 126 leakage current limits, 4-19 safety legal notes, i-17 human, 2-8 lighting, 3-4 safety precaution messages, 2-4 lockout/tagout (LOTO) requirements, 2-20 safety test overview, 4-16 LOTO service safety considerations, i-16 lockout/tagout requirements, 2-20 shipping/returning probes and repair parts, 2-21 site preparations, 3-1 time and manpower requirements, 3-20 standard hazard icons, 2-5 mains cable inspection, 4-8...
  • Page 127 © 2013-2018 General Electric Company. Manufacturer: GE Medical Systems www.gehealthcare.com...

Table of Contents
