GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code
Category
141/021
INHIBIT
141/022
INHIBIT
141/023
INHIBIT
141/024
INHIBIT
142/001
DEBUG
ONLY
142/003
INHIBIT
142/004
INHIBIT
142/005
INHIBIT
142/006
INHIBIT
142/007
INHIBIT
Chapter 9
Text in Log File or
on LCD
Coll PDO1 length
error
Coll PDO2 length
error
Coll PDO3 length
error
Coll PDO4 length
error
Coll 12V lamp power
failure
Coll front blade over-
current
Coll left blade over-
current
Coll rear blade over-
current
Coll right blade over-
current
Coll filter overcurrent Like blade overcurrent.
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
PDO[i] (for i=1 - 4) length error = it is a standard error
signal. The Gantry CPU sends a command message
which contains a certain number of databytes. In
case the length of the PDO is not adequate, this sig-
nal is produced.
PDO1: change FOV, PDO2: change filter type,
PDO3: lamp on/off, PDO4: change focal spot
Possible causes of error:
• Collimator has received bad data on its node
• Communication conflict/mismatch between system
and collimator
Actions to correct problem:
1. Check the cable connection (W409) between the
collimator and system, then restart system.
2. If the problem persists, change the CPU board
(re-calibrate the collimator afterwards).
3. If the problem persists, contact your OLC.
The power is down for 12 VDC (lamp).
See
JC DIAG A1401 LIGHT CENTERING FAILURE
on page 967
to fix the problem.
Axis[i] (for i=1 - 5) is protected = the axis is pro-
tected. This is either because the motor current is
over threshold for more than accepted range, or
there is abnormal noise on control board.
Possible reasons for overcurrent:
1. Mechanical resistance is too big
2. Control board failure
3. The frequency of system commands is too fast
See
JC DIAG A1406 COLL BLADE OVERCUR-
RENT on page 970
to fix the problem.
See
JC DIAG A1407 COLL FILTER OVERCUR-
RENT on page 970
to fix the problem.
Page no. 904
Senographe DS
Job Card
D/R A190
page
1131
CAL A029
page
1683
A1401
page 967
A1406
page 970
A1407
page 970
ERR-SUB-A-003.fm
