GE Senographe DS Manual page 861

GE Healthcare
Revision 1
Code Category
102/036 HALT
102/037 HALT
102/038 HALT
102/039 DEBUG
ONLY
102/040 HALT
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
LIFT TX CAN BUF-
FER OVERRUN
LIFT MAILBOX
OVERRUN
CPU HEARTBEAT
NOT RECEIVED BY
LIFT NODE
HEARTBEAT DIS-
ABLED ON LIFT
NODE
LIFT INVALID PDO
LENGTH
Possible Cause/Recommended Action
Possible causes:
• There has been a transmit queue overrun. The
transmit queue between the MCU and the DSP is
full and the message dropped.
• The TP1 connector on the Lift board is closed.
Proceed as follows:
Check whether a jumper exists on the TP1 connector
on the Lift board. In this case you must remove the
jumper from the TP1 connector on the Lift board.
If there is no jumper on the TP1 connector on the Lift
board, the Lift board is faulty. Change the Lift board
then perform a Lift Calibration.
The mailbox is overrun. The mailbox queue used in
the inter-task communication in the MCU is full and
the mails are dropped.
The Lift board is faulty. You must change the Lift
board then perform a Lift Calibration.
There has been a heartbeat failure. The Gantry CPU
did not send periodic "heartbeat" CAN message.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The Gantry CPU tried to disable the "heartbeat"
check of the lift node.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The lift node receives a PDO with an invalid DLC.
Refer to JC DIAG A1110 ROTATION CONTROL
FAILURE on page 952
Page no. 861
ERR SUB A003 - Gantry Error Messages
Job Card D/
1131).
Job Card
Job Card ELE
679).
Job Card D/
1131).
Job Card
Job Card ELE
679).
to fix the problem.
Senographe DS
Job Card
D/R A201
page
1161
CAL A031
page
1687
D/R A201
page
1161
CAL A031
page
1687
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
A1016
page 949
Chapter 9
