GE Senographe DS Manual page 282

GE Healthcare
Revision 1
Central Listing
3-1-2. Mains Distribution Assembly LEDs
LED
DS1 240 V from Primary Transformer
DS2
DS3 230 V from Primary Transformer
DS4 230 V DPS (APS_SPS)
DS5 Power ON ADS
DS6 Power ON DPS (APS_SPS)
DS7 Power ON Condtioner
Chapter 3
Function
230 V ADS
Service Information and Procedures Class A 2385072-16-8EN
Color
Clear Normal status: ON
ON when the 240 V Supply from the Primary Trans-
former is present.
OFF when there is a problem with 240 V Supply
from the Primary Transformer.
Clear Normal status: ON
ON when the 230 V AC supply to the Control Sta-
tion UPS is present.
OFF when there is a problem with the 230 V AC
supply to the Control Station UPS.
Clear Normal status: ON
ON when the 230 V Supply from the Secondary
Transformer is present.
OFF when there is a problem with 230 V Supply
from the Secondary Transformer.
Clear Normal status: ON
ON when the 230 V AC supply to the Detector
Power Supply is present.
OFF when there is a problem with the 230 V AC
supply to the Detector Power Supply.
Orange Normal status: ON/OFF
ON when the ADS is powered on via the Control
Station power button on the Service Interface.
OFF when the ADS is powered off via the Control
Station power button on the Service Interface.
Orange Normal status: ON/OFF
ON when the Detector Power Supply is powered
ON.
OFF when the Detector Power Supply is powered
OFF.
Orange Normal status: ON/OFF
ON when the Conditioner is powered ON.
OFF when the Conditioner is powered OFF.
Page no. 282
Senographe DS
Behavior
Indicators and Switches.fm
