GE Healthcare
Revision 1
Job Card DIAG A1000 - Gantry Diagnostic
2-29 JC DIAG A1208 COMPRESSION CONTROL FAILURE
Diagnostic for:
122/008 error code (CAN code is 0x5026) overcurrent error
•
First make a visual check of the motor cabling and its connection to the Compression Board.
•
Disconnect the cable W301 from connector J3.
-
Check on the cable connector for a short circuit. If you find one, change the compression motor +
encoder + cables (see
Belt on page
-
Measure the motor coil impedances. The impedances must measure 2 ohm between the blue
and pink wires, 2 ohm between the yellow and red wires. If not, change the motor + encoder +
cables(see
Job Card D/R A244 - Compression Motor with Encoder and Compression Belt on
page
1297).
•
If the error persists, change the Compression Board (see
on page
1323). Check the movement.
•
If the error persists, change the compression motor unit (see
Motor with Encoder and Compression Belt on page
FRUs:
2-30 JC DIAG A1212 COMPRESSION BRAKE FAILURE
Diagnostic for:
122/020 error code (CAN code is 0x500D) brake error
•
Check the B303 screw brake cable (W309) and brake coils by measuring the brake resistance. The
nominal resistance value is 192 ohm (+/-10 ohm). If the resistance values are out of these limits
change the brake and cables (see
1309).
•
Check the connector J5 on the Compression Board for damage. If damage is found, change the
Compression Board (see
•
Check the compression brake cable (W318) and brake coils by measuring the brake resistance. The
nominal resistance value is 230 ohm (+/-10 ohm).
If the resistance is out of these limits, change the brake and cables (see
Compression Brake on page
•
If the error persists, change the Compression Board (see
on page
1323).
FRUs:
Chapter 9
Job Card D/R A244 - Compression Motor with Encoder and Compression
1297).
Compression Board
Motor +Encoder with cable
Job Card D/R A247 - Motorized Compression Brake on page
Job Card D/R A250 - Compression Board on page
1301).
Compression brake+cable
Screwbrake +cable
Compression Board
Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A250 - Compression Board
1297).
Job Card D/R A250 - Compression Board
Page no. 960
Job Card D/R A244 - Compression
1323).
Job Card D/R A246 - Manual
Senographe DS
JC-DIAG-A-1000.fm
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
