Cable Lay-out and Pin-out
1-52. W305 - Arm Control Keypad Connect
FromArm Control Keypad PL305 J1 (on right or left of Arm) to Compression Board PL303 J7 or J8:
1-53. W306 - Earth Cable Arm Connect
Arm to ground bar G301.
1-54. W307 - 48v dc-LP2 for Compression
Arm Distribution Board PL301 J5 to Compression Board PL303 J1:
Chapter 3
Service Information and Procedures Class A 2385072-16-8EN
Designation
Lift up slow speed_A
Lift up slow speed_B
Lift up High speed_A
Lift up High speed_B
Lift down slow speed_A
Lift down slow speed_B
Lift down High speed_A
Lift down High speed_B
Rotation left slow speed_A
Rotation left slow speed_B
Rotation left high speed_A
Rotation left high speed_B
Rotation right slow speed_A
Rotation right slow speed_B
Rotation right high speed_A
Rotation right high speed_B
MLO_R_A
MLO_R_B
MLO_L_A
MLO_L_B
CC_A
CC_B
Spare_1_A
Spare_2_B
GND
+VCC 5 V
Pin N°
PL301/J5-1
PL301/J5-2
Level
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
Contact to gnd
GND
VCC
Function
48 Volts
GND
