Job Card PHY A009 - Opposite Side Rotative Arm Installation

1 SUPPLIES
• Spare USB extension cable connected to the Control Station framework below the keyboard.
• Left stop bracket (PN 5235174-2) : one ring labeled L.
L
Note:
The left stop bracket (PN 5235174-2) can be found in the Accessories box that is delivered with
the Senographe system. The Accessories box (located in the large wooden Accessories cabinet)
contains the ADS/IDC Software, Loopback Kit, Service Documents, etc..
2 TOOLS
• Standard Tool Box
• Sisfle Rotative Arm Installation Tool
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 1 hour
4 SAFETY PRECAUTIONS
None
5 PREREQUISITES
None
