GE Healthcare
Revision 1
Job Card ELE A009 - Generator Configuration
5-3
Check Presence Parameters
The following equipment presence parameters must normally be set to YES:
•
Gantry (Arm) presence; SETUP/GENE/INSTAL/GENE/CONFIG/CONFIG/PRES/PRS-B
•
Digital System presence; SETUP/GENE/INSTAL/GENE/CONFIG/CONFIG/PRES/PRS-DS
•
IDC presence; SETUP/GENE/INSTAL/GENE/CONFIG/CONFIG/PRES/PRS-IDC
•
Perform a checksum (SETUP/GENE/INSTAL/CKSUM/CKSUM) and return to the Application mode.
5-4
Check Paddle Deformation Parameters
•
Check the values of paddle deformation parameters against the default factory settings are all set to
0.000 E+0. These parameters alter the X-ray exposure behavior in AOP mode.
18 x 24 paddle in contact mode: access
SETUP/GENE/INSTAL/GENE/AOP/PELOTE/18x24
Magnification paddles: access
SETUP/GENE/INSTAL/GENE/AOP/PELOTE/MAGN
•
Do not perform any modification of the Paddle deformation parameters.
Chapter 7
Service Information and Procedures Class A 2385072-16-8EN
Paddle
Standard metallic arm
paddle (*)
All magnification
paddles(*)
Page no. 564
Senographe DS
Offset Value
Gain Value
0
0
0
0
JC-ELE-A-009.fm
