Job Card DIAG A1000 - Gantry Diagnostic
Check the potentiometer resistance between pins 1-2, 1-3, and 2-3. The acceptable resistances
between the pins are summarized in the table below.
Pins 1-3 (Resistance 1)
Pins 1-2 (Resistance 2)
Pins 2-3 (Resistance 3)
Resistance 2 + Resistance 3 must be between
If the measured resistance is not between the excepted limits, change the Compression Potentiome-
ter (see Job Card D/R A243 - Compression Potentiometer and Cable on page
Note:
The new Compression Potentiometer ordered will be a Type 3 Compression Potentiometer.
• If the error persists, check that the potentiometer screw runs normally as the trolley moves. If the
potentiometer screw does not move normally, change the Compression Potentiometer (see
D/R A243 - Compression Potentiometer and Cable on page
• If the error persists, change the compression motor and encoder (see
pression Motor with Encoder and Compression Belt on page
• If the error persists, change the Compression Board (see
on page 1323).
FRUs:
Recalibration is necessary if the Compression Board or the potentiometer is changed.
2-28 JC DIAG A1206 COMPRESSION CONTROL FAILURE
Diagnostic for:
122/006 error code (CAN code is 0x502B) step lost error
122/007 error code (CAN code is 0x6004) overspeed error.
• First make a careful visual check of the mechanical parts:
worm gear, upper (screw) brake, timing belt, motor unit.
• If no mechanical defect is detected:
- Check the brake air gap. The gap must be 0.2 mm for correct operation.
- Check the incremental encoder cable (W302) and its connection on the Compression Board (J4).
• Check the brake cable (W309) and brake coils by measuring the brake resistance. The resistance
value must be 192 ohm (+/-10 ohm). If it is out of these limits, change the brake and cables (see
Card D/R A246 - Manual Compression Brake on page
• If the error persists, remove power from the Compression Board. Apply 48 VDC on the brake cable
connector (check polarity!), then try to move the mechanics manually by pulling on the timing belt.
- If you cannot move by hand, first oil the mechanics.
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Resistance on Type 1
or Type 2
Compression
Potentiometer
0.9 kOhm to 1.1 kOhm
0 kOhm to 1.1 kOhm
0 kOhm to 1.1 kOhm
0.9 kOhm to 1.1 kOhm
Pot+cable
Mot+Enc with cable
Timing belt
Compression Board
1301).
Page no. 958
Resistance on Type 3
Compression
Potentiometer
9 kOhm to 11 kOhm
0 kOhm to 11 kOhm
0 kOhm to 11 kOhm
9 kOhm to 11 kOhm
1289).
Job Card D/R A244 - Com-
1297).
Job Card D/R A250 - Compression Board
Senographe DS
1289).
Job Card
Job
