GE Healthcare
Revision 1
9
ADS REAR PANEL CONNECTORS (SUN U20 WORKSTATION)
Reference
1
2
3
4
5
6
7
8
9
10
11
12
3
4
6
Note: Ensure that the monitor DVI cable is
connected to the left hand side DVI connector
on the back of the ADS computer.
JC-DR-A-311.fm
External Ethernet Link (to hospital network)
Generator-UPS-ADS Serial Link 2387162
Internal Ethernet Switch (IDC, AWS, Gantry)
(2389288 on Pre-Penduick systems, 2389288-2 on Penduick and above systems)
Ground
VGA Socket
NOT used
5
12
7
Service Information and Procedures Class A 2385072-16-8EN
Function
AC input
Monitor DVI Cable 5177284-2
Mouse or Trackball USB Link
Keyboard USB Link
Bar Code Reader USB Link
Not used
Generator Serial Link 2226625
Service-specific cable
Not used
1
2
8
10
Page no. 1415
Senographe DS
Job Card D/R A311 - AWS Unit
9
11
Chapter 9
