Job Card D/R A322 - RJ-45 Service Network Patch Panel

1 SUPPLIES
RJ-45 Service Network Patch Panel
2 APPLICABILITY
This Job Card is only applicable to Penduick and above V3 Control Stations and V4 Control Stations.
3 TOOLS
Standard Tool Box
4 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 30 minutes
5 SAFETY PRECAUTIONS
WARNING
Before beginning work, shut down correctly the equipment and switch off the Senographe
system hospital supply circuit breaker. Lock it in the off position or mark it clearly with a
warning sign to prevent others from applying power.
6 PREREQUISITES
None
