GE Healthcare
Revision 1
Job Card CAL A009 - X-Ray Tube mA Measurement
1
SUPPLIES
None
2
TOOLS
•
Meter for measurement of mA. The meter must be in good condition and possess valid certification.
Suitable meters are:
-
Fluke 87 multimeter
-
Keithley 35035 mAs meter
-
GS Poner 165 mA-mAs meter
3
REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 27 minutes
4
SAFETY PRECAUTIONS
None
5
PREREQUISITES
None
6
CALIBRATION OF X-RAY TUBE MA MEASUREMENT
The objective is to determine the scale factor F/mA between the X-ray tube mA measurement input to
the software and the real X-ray tube mA value.
The default parameter value is F/mA = +1.000E+3 (1000) Hz/mA
CAUTION
DO NOT touch potentiometer P1 on generator kV/mA board 701-PL1 at any point in this
procedure.
JC-CAL-A-009.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card CAL A009 - X-Ray Tube mA Measurement
Page no. 1663
Senographe DS
Chapter 9
Chapter 9
