GE Senographe DS Manual page 1326

GE Healthcare
Revision 1
Job Card D/R A250 - Compression Board
Connector
Label
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
J21
J22
3. Ensure that jumper JP1 (3) that is to the left of the J6 connector on the Compression board is open.
3
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Description of cable
(usually identified by code on a yellow label)
J1/PL303-W307
J2/PL303-W308
J3/PL301-W301
J4/PL301-W302
J4/PL303-W309
covered with flexible plastic
J6/PL303-W303
J7/PL303-W305
Note: Only connected when replacing the covers.
J8/PL303-W305
Note: Only connected when replacing the covers.
J9/PL303-W313
J7/PL303-W304
Empty
Empty
Page no. 1326
Senographe DS
Cable color
Gray
Gray
Red, Blue,
Orange,
Yellow
Gray ribbon
Red/Green
Blue/Green
Black, Red,
Green
Light brown
ribbon
Light brown
ribbon
Grey robbon
Gray
N/A
N/A
JC-DR-A-250.fm
