GE Healthcare
Revision 1
Job Card D/R A313 - Trackball
Three types of Rotative Arm Sets exist, as follows:
•
Ergotron A (introduced with V1 Control Stations) - contains one rotative arm support and two exten-
sion (rotative) arms
•
Ergotron B (introduced with V2 Control Stations and with early V3 Control Stations) - contains one
rotative arm support and two extension (rotative) arms
•
Sisfle (introduced with V3/V4 Control Stations) - contains one rotative arm support and one extension
(rotative) arm
The procedure used in this Job Card vary according to the type of rotative arm you have.
1
SUPPLIES
ADS Trackball Kit
2
TOOLS
Standard Tool Box
3
REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 60 minutes
4
SAFETY PRECAUTIONS
WARNING
Before beginning work, shut down correctly the equipment and switch off the Senographe
system hospital supply circuit breaker. Lock it in the off position or mark it clearly with a
warning sign to prevent others from applying power.
5
PREREQUISITES
Calibrate the new replacement Trackball on a laptop in a quiet area (see
Configuration on page
JC-DR-A-313.fm
787).
Service Information and Procedures Class A 2385072-16-8EN
Page no. 1427
Senographe DS
Job Card D/R A313 - Trackball
Chapter 9
Job Card ELE A065 - Trackball
Chapter 9
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
