the ground cable from the Paddle Holder.
J1 : Force Sensor
(J1 / PL304 - W304)
J3 : Manual Compression Brake
(J3 / PL304 - W314)
4. Taking care not to damage the earth cable, cut the cable ties (4) that secure the Paddle Recognition
cable to the side of the Compression Arm framework..
6
5. Carefully disconnect the D-connector (5) of the Paddle Recognition cable from the cable that leads to
the D-Connector (6) of the cable leading to the Compression Board.
JC-DR-A-249.fm
5
Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A249 - W304 Cable for Paddle Recognition
J2 : Paddle Recognition Cable
(J2 / PL304 - W319)
4
Page no. 1321
Senographe DS
Paddle Holder
Earth Cable
Chapter 9
