GE Healthcare
Revision 1
Job Card D/R A261 - X-ray Tube Assembly
1
SUPPLIES
•
X-ray tube assembly
•
Silicone Lubricant which is supplied with the X-ray tube assembly
2
TOOLS
•
Standard Tool Box
•
Trolley
3
REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 4 to 5 hours including all calibrations and functional checks
4
SAFETY PRECAUTIONS
WARNING
Be careful when touching the tube housing, as its temperature can be up to 80
°
180
F).
5
PREREQUISITES
•
Select Aluminium filter (to avoid possible damage to rhodium or molybdenum filters).
•
Rotate the arm to 90° to access the X-ray Tube.
•
Switch off the Gantry power.
•
Remove the tube cover (refer to
523).
•
Remove the tilt motor and drive assembly (refer to
bly on page
1361).
6
PROCEDURE
! Notice:
Take great care to avoid damage to the rhodium filter, since it is expensive.
JC-DR-A-261.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A044 - Remove/Reinstall Gantry Covers on page
Job Card D/R A265 - Tilt Motor and Drive Assem-
Page no. 1353
Job Card D/R A261 - X-ray Tube Assembly
Senographe DS
Chapter 9
°
C (about
Chapter 9
