Job Card D/R A415 - Generator Board CPU EEPROMs
TABLE 1 - GENERATOR CPU BOARD EEPROMS AND CORRESPONDING SOCKETS
Generator
EEPROM kit
version
1.10 CMN
3.02 CMN
5405814
4.02 CMN
5411745
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Set of EEPROMs
EEPROM P/N
5405832
5405833
NA
Page no. 1628
Corresponding
board socket
2385604-8
2385605-8
2385606-8
2385607-8
2385604-9
2385605-9
2385606-9
2385607-9
2385604-11
2385605-11
2385606-11
2385607-11
Senographe DS
Corresponding
label reference to
stick on Genera-
tor CPU Board
B43
B44
2385602-8
B48
B49
B43
B44
2385602-9
B48
B49
B43
B44
2385602-11
B48
B49
JC-DR-A-415.fm
