rent for the two points (4.0 and 5.0 A) should become increasingly accurate. If not, the procedure
is probably not being followed correctly.
10. Select SETUP/SETUP/SETUP/PARAM on the X-ray Console. Note down the calculated values of
scale factor K and offset VOF. The two values can be displayed alternately by rotating the X-ray Con-
sole kV dial.
CAUTION
If the value of K is less than +8.000E+0 (8.0), either the calibration procedure was done
incorrectly or there is a hardware defect.
11. Repeat the calibration and check procedures on the other tube track, if necessary.
12. Perform a checksum (SETUP/GENE/INSTAL/CKSUM/CKSUM), then turn the system off.
13. Reconnect flat cable WG8 to generator command board 400-PL1 connector XJ7; Remove the high
voltage cable adapter. Remember to secure the HV ring allen screw, to ensure proper ground conti-
nuity.
7 COMPLETION
If you are handing the machine back to the user at this point, switch the Senographe off, then on again.
