GE Healthcare
Revision 1
Job card D/R A252 - Compression Trolley Kit
1
SUPPLIES
Compression Trolley Kit
2
TOOLS
Standard Tool Box
3
REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 30 minutes
4
SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5
PREREQUISITES
•
Switch off the Gantry power.
6
PROCEDURE
1. Remove the Compression Carriage covers (refer to
Reinstall Gantry Covers on page
2. Remove the Compression trolley (refer to
Gantry Covers on page
3. Change the old Compression trolley for a new Compression trolley (refer to
PHY A044 - Remove/Reinstall Gantry Covers on page
4. Replace the original Compression Carriage covers (refer to
Remove/Reinstall Gantry Covers on page
JC-DR-A-252.fm
Service Information and Procedures Class A 2385072-16-8EN
(comprising Paddle Holder, and W304B Cable)
523).
523).
Job card D/R A252 - Compression Trolley Kit
section 8-1
section 8-2
in
Job Card PHY A044 - Remove/Reinstall
523).
section 8-1
523).
Page no. 1337
Senographe DS
in
Job Card PHY A044 - Remove/
section 8-2
in
Job Card PHY A044 -
Chapter 9
in
Job Card
Chapter 9
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
