Revision 1

Job Card D/R A405 - HV Cable

1 SUPPLIES
HV Cable
HV grease
2 TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 2 Field Engineers
Time: 5 hours
4 SAFETY PRECAUTIONS
The procedures in this Job Card produce X-rays. Ensure that you take appropriate precautions when
operating with X-rays (for example, stay behind the radiation screen during an X-ray exposure).
5 PREREQUISITES
None
6 PROCEDURE
6-1 Removal and re-installation of the HV Cable
1. Switch off the electrical power supply from the Mains Distribution Panel in the room. Apply an appro-
priate LOTO padlock and label. Wait 10 minutes for the components within the Generator to dis-
charge.
2. Remove the Generator covers (see
page 513).
3. Remove the Gantry covers (see
523).
4. Disconnect the cable from the Generator HV tank and from the Tube connector J2.
5. Remove the cable.
! Notice:
When it is necessary to cut cable ties which secure the cable to mechanical components or to oth-
er cables, take care to note or mark the exact position of the cable. This is required so that replace-
ment of the cable can be made in the same manner. Refer to section
positioning information.
6. Install the replacement cable; position it as described below. Use HV grease on the HT connection as
required.
JC-DR-A-405.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A042 - Remove/Reinstall Generator Covers on
Job Card PHY A044 - Remove/Reinstall Gantry Covers on page
Page no. 1565
Senographe DS
Job Card D/R A405 - HV Cable
Chapter 9
6-2 for specific cable
Chapter 9
