7 COMPLETION
In normal circumstances there is nothing to do. However, if the Generator configuration was lost in one
of the following situations, the Generator must be reconfigured:
• the original battery was too low before you arrived
• a problem occured during the backup procedure and you failed to solder the battery correctly
If Generator reconfiguration is necessary:
• carry out the following calibrations:
Calibrations - Checks
Acquisition Image Chain
Heating Current Calibration
Bias Calibration
Tube mA Measurement
kV Scale Factor
mAs X-ray Calibration
Bad Pixel Calibration
Gain calibration
flat field tests
Half Value Layer
Conversion Factor
AOP: Automatic Optimization of Parameters
AOP Calibration
mAs non linearity
AOP/SNR Check
If AOP/SNR Test not OK, repeat all calibrations from AOP Calibration.
• For Senographe systems that use AWS V43.0 or later (on the SB150) or AWS 53.0 or later (on the
U20), if the Senographe system does not use the default AOP Classic (AOP A) tables configuration,
restore as necessary the AOP configuration (see
693).
JC-DR-A-402.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card CAL A001 - Heater Current Scale Factor on page 1649
Job Card CAL A003 - X-Ray Tube Focal Bias Voltage Scale Factor on
page 1655
Job Card CAL A009 - X-Ray Tube mA Measurement on page 1663
Job Card CAL A011 - Calibration of kV Scale Factor on page 1667
Job Card CAL A012 - X-Ray Tube Heater Current on page 1673
Job Card CAL A041 - Bad Pixel Calibration on page 1693
Job Card CAL A043 - Detector Gain Calibration on page 1697
Job Card ELE A032 – IQ Tools Flat Field Test on page 699
If IQ Tests not OK, repeat all calibrations from Bad Pixel.
Job Card CAL A046 - Half-Value Layer Measurement on page 1703
Job Card CAL A045 - Conversion Factor Measurement on page 1701
Use the same dosimeter as that used for CAL A046
Job Card CAL A051 - AOP Calibration on page 1723
Job Card CAL A053 - mAs Non-linearity Calibration on page 1725
Job Card ELE A038 - AOP Mode and SNR Check on page 707
Job Card D/R A402 - Generator CPU Battery
Job Card
Job Card ELE A031 - AOP Configuration on page
