Overview
The TigerSHARC processor supports many system design options. The
options implemented in a system may be influenced by cost, performance,
and system requirements. This chapter discusses the following topics:
• "TigerSHARC Processor Pins" on page 10-3
• "Power, Reset, and Clock Input Considerations" on page 10-11
• "Reset and Boot" on page 10-17
• "Booting a Multiprocessor System" on page 10-26
• "JTAG Issues" on page 10-38
• "Resources and References" on page 10-38
Refer to Table 10-1 to locate additional information for system design.
Table 10-1. Additional Reference Material
Topic
Power Supply Sequence
Reset Sequence
Clock Domain
High Frequency Design
10-2
Can be found in this document...
See "Power Supplies" in ADSP-TS101 TigerSHARC Embedded Pro-
cessor Data Sheet.
See "Reset and Booting" in ADSP-TS101 TigerSHARC Embedded
Processor Data Sheet.
See "Clock Domain" in ADSP-TS101 TigerSHARC Embedded Pro-
cessor Data Sheet.
see the Technical article ADSP-TS101S MP System Simulation and
Analysis which can be found on the Analog Devices Web site
http://www.analog.com.
ADSP-TS101 TigerSHARC Processor
Hardware Reference
