DY_MODIFY
•
DX_COUNT
If the field is 3 (quad-word), the values must all be multiplicands of 4
LEN
(Bits1–0 cleared).
For type = 6 (boot EPROM), these registers must all be multiplicands of 4
(Bits1–0 cleared).

Address Range

The following correlation must exist between the
and the address any time the
= 1 (link) ⇒ address is of one of the link transmit registers (see
•
TY
"Link Registers" on page 2-47).
= 2 (internal memory) ⇒ address is in internal memory range,
•
TY
and not in the registers (see "Internal Address Space" on page 2-6).
= 4 (external memory) ⇒ address is in external memory range
•
TY
(address31–22 non-zero). It can be in host, external memory or
multiprocessing space.
!
When a link DMA channel (transmit or receive channel) becomes
active, if the transmit buffer is empty (for transmit channel) or if
the receive buffer is not empty (for receive channel), a DMA
request is immediately issued.
ADSP-TS101 TigerSHARC Processor
Hardware Reference
(if relevant)
is active:
TCB
Direct Memory Access
field in the
TY DP
register
7-31
