ADX16A-PT (AUDIX Analog Line/Control Link)

ADX16A-PT (AUDIX Analog
Line/Control Link)
MO Name (in
Alarm Log)
ADXCL-PT or MINOR
ADX16A-PT
ADXCL-PT or WARNING
ADX16A-PT
1. Where P is the port network number (1 for PPN); C is the carrier designation (for example, A, B, or
C); SS is the address of the slot in the carrier where the circuit pack is located (for example, 01,
02, etc.); and pp is the 2-digit port number (for example, 01).
!
CAUTION:
Never do any of the following without first shutting down AUDIX. Follow
instructions in the
''Maintenance for CSI
The ADX16A-PT maintenance object represents a port on a TN566/TN2169
EMBEDDED AUDIX circuit pack that is operating in control-link (CL) mode. For
circuit-pack-level problems (ADX16A-BD or ANL-16-BD), see "XXX-BD (Common
Port Circuit Pack)". For port-level problems with AUDIX operating in digital-port
mode, see ADXDP-PT/ADX8D-PT.
The tests described in this section apply only to switch-side maintenance which
tests circuit pack components related to the TDM bus interface. The AUDIX
system has an extensive maintenance strategy that is described in EMBEDDED
AUDIX System Maintenance, 585-300-110.
AUDIX resides on a combined pair of circuit packs: the TN566 Multifunction Board
(MFB) and the TN2169 Alarm Board (ALB). Because of its size this combination
occupies 5 slots, but only 1 slot is functional as far as the switch is concerned. The
other 4 slots are seen by the switch as ''AUDIX-reserved'' slots.
In CL mode the TN566 pack supports up to 16 voice ports. When a call to a
station with an AUDIX login is not answered, AUDIX answers the call using one of
the available voice ports.
Unlike other AUDIX systems, EMBEDDED AUDIX is not an adjunct.
555-233-119
Alarm Initial Command To
Level Run
test port PCSSpp l
test port PCSSpp sh
''Power Down AUDIX System''
systems''.
1
Full Name of MO
AUDIX Analog Line/ Control Link
AUDIX Analog Line/ Control Link
section in
Issue 5 October 2002
Chapter 1,
631
