Avaya DEFINITY Server CSI Maintenance Manual page 644

Maintenance Objects
Table 38. TEST #6 NPE Crosstalk Test — Continued
Error Test
Code Result
2000 ABORT
2100 ABORT
Any FAIL
PASS
0 NO
BOARD
644
Issue 5 October 2002
Description/Recommendation
Response to the test request was not received within the allowable time
period.
System resources required to run test are not available. This could be due
to a failure to seize the port.
1. Retry the command at 1-minute intervals a maximum of 5 times.
This test can fail due to on-board or off-board problems. Off-board
problems include EXP-PN and EXP-INTF faults, TDM-BUS faults, and
faults associated with the tone detectors/tone generators. Clear all
off-board problems before replacing the board. A TDM-BUS problem is
usually the result of a faulty board connected to the backplane, or bent pins
on the backplane.
1. Look for EXP-PN and/or EXP-INTF errors in the error log. If present,
refer to "EXP-PN" and "EXP-INTF".
2. Look for TDM-BUS errors in the error log. If present, refer to
"TDM-BUS".
3. Look for TONE-BD and/or TONE-PT errors in the error log. If present,
refer to "TONE-BD" and "TONE-PT".
4. Test the board when the faults from Steps 1, 2, and 3 are cleared.
Replace the board if the test fails.
The port is correctly using its allocated time slots. User-reported troubles
on this port should be investigated by using other port tests, by examining
station wiring, or by examining the station.
The test could not relate the internal ID to the port (no board). This could be
due to incorrect translations, no board is inserted, an incorrect board is
inserted, or an insane board is inserted.
1. Check to ensure that the board translations are correct. Use list
config and resolve any problems.
2. If the board was found to be correctly inserted in step 1, use busyout
board.
3. Issue reset board.
4. Issue release busy board.
5. Issue test board long. This should re-establish the linkage between
the internal ID and the port. If this is not the case, check to ensure that
there is a valid board inserted.
Continued on next page
555-233-119
