Description Field - 3Com S7906E Command Reference Manual

Field
AS
MsgRcvd
MsgSent
OutQ
Up/Down
State
# Display detailed information about BGP VPNv4 peer 1.1.1.1.
<Sysname> display bgp vpnv4 all peer 1.1.1.1 verbose
Peer: 1.1.1.1
Type: IBGP link
BGP version 4, remote router ID 1.1.1.1
BGP current state: Established, Up for 00h46m01s
BGP current event: RecvKeepalive
BGP last state: OpenConfirm
Port: Local - 1039
Configured: Active Hold Time: 180 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv4 Unicast: advertised and received
Address family VPNv4: advertised and received
Received: Total 52 messages, Update messages 2
Sent: Total 65 messages, Update messages 5
Maximum allowed prefix number: 150000
Threshold: 75%
Minimum time between advertisement runs is 15 seconds
Optional capabilities:
Route refresh capability has been enabled
Nesting-vpn peer (vpn-instance vrf1) has been configured
Connect-interface has been configured
Peer Preferred Value: 0
Routing policy configured:
No routing policy is configured
Table 1-8 display bgp vpnv4 all peer verbose output description
Field
Peer
Local
Type
AS number
Number of messages received
Number of messages sent
Number of messages waiting to be sent to the peer
Duration of the BGP session in the current state
Status of the peer
Local: 2.2.2.2
Remote - 179
IP address of the peer
IP address of the local router
BGP type
1-13
Description
Keepalive Time:60 sec
Description
