Job Card CAL A051 - AOP Calibration
(about 20 seconds), then CALIBRATION END appears on the X-ray Console display. Release the
Exposure button
9. Perform a checksum (SETUP/SETUP/SETUP/SETUP/SETUP/SETUP/CKSUM/CKSUM).
10. Exit the Calibration Menu (SETUP/SETUP/SETUP//SETUP/SETUP).
7-3 Calibration with Stereo configuration
Note:
This calibration is applicable only if the Stereo option is present.
1. Remove the Bucky and insert the Stereotix with the paddle without biopsy window.
2. Place the Flat Field Phantom on the Stereotix.
3. Compress the acrylic.
4. Select Large Focal Spot from the X-ray Console.
5. From the X-ray Console, enter the SETUP/GENE/INSTAL/GENE/AOP/APOLLO/CALIB/
NOGRIDLF menu.
6. Press CALIB.
7. Press the Exposure button
(about 20 seconds), then CALIBRATION END appears on the X-ray Console display. Release the
Exposure button
8. Perform a checksum (SETUP/SETUP/SETUP/SETUP/SETUP/SETUP/CKSUM/CKSUM).
9. Exit the Calibration Menu (SETUP/SETUP/SETUP/SETUP/SETUP).
7-4 Calibration with No Grid/Small Focal Spot configuration
Note:
This calibration is applicable only if the Magnification option is present.
1. Remove the Bucky.
2. Install the 1.8 magnification Mag Stand; the calibration switches automatically to Small Focal Spot
configuration.
3. Place the Flat Field Phantom on the magnification stand.
4. Compress the phantom at 4daN using the standard 19 x 23 Magnification paddle (Ref. Number
2397559).
5. From the X-ray Console, enter the SETUP/GENE/INSTAL/GENE/AOP/APOLLO/CALIB/
NOGRIDSF menu.
6. Press CALIB.
7. Press the Exposure button
(about 20 seconds), then CALIBRATION END appears on the X-ray Console display. Release the
Exposure button
8. Perform a checksum (SETUP/SETUP/SETUP/SETUP/SETUP/SETUP/CKSUM/CKSUM).
9. Exit the Calibration Menu (SETUP/SETUP/SETUP/SETUP/SETUP).
8 COMPLETION
If you are handing the machine back to the user at this point, switch the Senographe off, then on again.
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
.
on the X-ray Console and hold it down. Three exposures are taken
.
on the X-ray Console and hold it down. Three exposures are taken
.
