Wall Sweep Properties

You can modify several properties for wall sweeps, including profiles and offsets.
Modifying Wall Sweep Properties
1 In a 3D or elevation view, select a wall sweep and click
2 In the Element Properties dialog, edit wall sweep instance parameters.
3 Click Edit/New to edit wall sweep type parameters.
Changes made to type properties affect all wall sweeps of this type in the project. You can click
Duplicate to create a new wall sweep type.
4 When you are finished, click OK.
Wall Sweep Type Properties
Name
Constraints
Cuts Wall
Cut by Inserts
Default Setback
Construction
Profile
Materials and Finishes
Material
Identity Data
Subcategory of Walls
Description
When selected, the sweep will cut geometry out of the host wall if there is an overlap.
Setting this value to No can increase performance on large building models with
many sweeps.
When selected, inserts such as doors and windows cut geometry out of the sweep.
See Sweeps and Reveals Commands
This value specifies the distance the sweep is set back from each intersecting wall
insert.
Specifies the profile family used to create the wall sweep.
Sets the material of the wall sweep.
By default, wall sweeps are set to the Wall Sweep subcategory of walls. In the Object
Styles dialog, you can create new Wall subcategories and subsequently select one
here. This allows you to modify wall sweep style at a project level using the Object
Styles dialog.
(Element Properties).
on page 573.
Wall Sweeps | 597
