2 Select it and click
3 In the Element Properties dialog, click Edit/New.
4 Specify a value for the Elevation Origin parameter. For more information about the values, see
5 If you set the elevation to Relative, click OK, and set the value for the Relative Base instance
Changing Spot Elevation Arrowhead Style
1 Click Settings menu
2 For Type, select Filled Elevation Target.
3 For Arrow Style, select Elevation Target.
4 If desired, select Fill Tick. If you select this option, the arrowhead looks like the filled elevation
5 Click OK.
6 Place a spot elevation.
7 Select the spot elevation, click
8 For Type, select Target Leader.
9 For Leader Arrowhead, select Filled Elevation Target.

Reporting North, South, East, and West Spot Coordinates

Spot coordinates report the North/South and East/West coordinates of points in a project.
You can also display the elevation of the selected point and indicator text in addition to the coordinates.
230 | Chapter 5 Using Dimensions and Constraints
Spot Elevation Type Properties
parameter.
Annotations
symbol: . If you do not select this option, the arrowhead is a crosshairs symbol:
NOTE The Filled Elevation Target type is available for other annotations, such as text note leaders.
(Element Properties).
on page 241.
Arrowheads.
(Element Properties), and click Edit/New.
.
