4 Click in the drawing area to place the room.
5 If you placed a tag with the room, name the room as follows:
If you place a room inside bounding elements, it expands to the element boundaries. You can also place a
room in a free space or one that is not entirely bounded, and then draw room-bounding elements around
the room later. When you add bounding elements, the room expands to the boundaries. See
on page 915.

Selecting a Room

You can select rooms in plan views and section views. Select a room to check its boundaries, change its
properties, remove it from the model, or move it to another location.
To select a room, move the cursor over the room until its reference lines display, and click. You can also
place the cursor over the room perimeter, press TAB to cycle through choices until the reference lines display,
and then click.
A selected room in a plan view
A selected room in a section view
Move a selected room by dragging it using the move control. If the room has a tag, move the tag with the
room by selecting both and dragging them to the new location. As an alternative, you can delete the tag
before moving the room, and then tag the room in its new location.
914 | Chapter 14 Rooms and Areas
To see room-bounding elements, click Show Bounding Elements.
Revit Architecture highlights all room-bounding elements in gold, and displays a warning.
To see a list of all room-bounding elements in the model, including those that do not display
in the current view, click Expand in the warning dialog. To exit the warning and remove
the highlighting, click Close.
NOTE Revit Architecture will not place a room in a space that is less than 1' or 306 mm wide.
a On the Design Bar, click Modify.
b In the room tag, click the room text to select it, and replace it with the room name.
Room Boundaries
