Isolated Foundation Properties

You can use several standard types of isolated foundations: either Rectangular Footings, Concrete Pile-Caps,
or Steel Pipe Piles.

Modifying Isolated Foundation Properties

You can edit isolated foundation properties, such as those indicating structure, dimension, and identity.
To edit isolated foundation properties
1 Select the isolated foundation, and click
2 In the Element Properties dialog, edit isolated foundation instance parameters as required.
3 Click Edit/New to edit isolated foundation type parameters.
4 When you are finished, click OK.

Isolated Foundation Type Properties

Name
Dimensions
Width
Length
Thickness
Identity Data
Assembly Code
Keynote
Model
Manufacturer
Type Comments
862 | Chapter 12 Working with Structural Components
NOTE Changes made to type parameters affect all isolated foundations of this type in the project.
You can click Duplicate to create a new isolated foundation type.
Description
Specifies the width of the isolated foundation type. Applies to the Pile Cap Pile
family type.
Specifies the length of the isolated foundation type. Applies to the Pile Cap Pile
family type.
Specifies the foundation thickness. Applies to the Pile Cap Pile family type.
A uniformat assembly code selected from hierarchical list.
Add or edit the isolated foundation keynote. Click in the value box to open the
Keynotes dialog. See
The manufacturer internal number.
The foundation manufacturer.
A field for placing general comments about the foundation type. This information
can be included in a schedule.
.
Keynotes on page 1058.
