Spot Coordinate Instance Properties - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Units Format
Text Location
Elevation Indicator
Coordinate Origin
Top Value
Bottom Value
North/South Indicator
East/West Indicator
Include Elevation
Indicator as Prefix / Suffix

Spot Coordinate Instance Properties

Name
Graphics
Leader Shoulder
Leader
Text
Top Value Prefix
Top Value Suffix
246 | Chapter 5 Using Dimensions and Constraints
Description
Click the button to open the Format dialog. Clear the Use Project Settings option,
and set the appropriate values. See
Specify the position of the spot coordinate with respect to the leader. Options include
Above Leader, Below Leader, or In-line with Leader.
When you specify In-line with Leader, the elevation symbol does not display for the
spot coordinate. In addition, the Text Offset from Leader, Text Offset from Symbol,
and Symbol properties are disabled.
A text string you enter with the spot elevation. Can be displayed as a prefix or suffix
with the Indicator as Prefix/Suffix parameter.
Indicates that the coordinates are shared. This is a read-only value.
Determines which coordinate value is placed on top.
Determines which coordinate value is placed on the bottom.
Lets you specify how to label the north/south direction. For instance, you might
enter X.
Lets you specify how to label the east/west direction. For instance, you might enter
Y.
Displays the spot elevation in addition to the spot coordinates.
Specifies placement of the North/South, East/West, and Elevation indicators.
Description
When Leader is selected, you can add a shoulder (a bend) to the leader line.
If selected, the spot coordinate includes a leader line. When not selected, no leader
line appears.
Specify prefix text for the top spot coordinate.
Specify suffix text for the top spot coordinate.
Setting Project Units on page 492.
