Name
z-Direction Offset Value
Lateral Justification
Orientation
Cross-Section Rotation
Construction
Start Extension
End Extension
Materials and Finishes
Beam Material
Structural
Stick Symbol Location
Moment Connection Start
Moment Connection End
Cut Length
Structural Usage
Rebar Cover - Top Face
Rebar Cover - Bottom Face
Rebar Cover - Other faces.
Description
The numeric value that offsets the geometry.
The location of the physical geometry (in plan) with respect to the location
line. Either Side 1, Side 2 and Center. Read-only when pinned.
The beam orientation to the current plane on which elements are placed.
This is a read-only value.
Parameter that controls rotating beams and braces. The angle of rotation is
measured from the beam's work plane and the direction of the center reference
plane.
Applies to steel beams only. The dimension between the edge of the start
end of the beam and the element to which it is connected.
Applies to steel beams only. The dimension between the edge of the finish
end of the beam and the element to which it is connected.
The structural material. See Material Physical Type Parameters
Applies to steel beams only.
Applies to steel beams only. A moment frame, or cantilever symbol at the
start end of a beam.
Applies to steel beams only. A moment frame, or cantilever symbol at the
finish end of a beam.
The physical length of the beam. This is a read-only value.
Specifies the usage. Either Girder, Horizontal bracing, Joist, Other, or Purlin.
Applies to concrete beams only. The rebar cover distance from the beam top
face.
Applies to concrete beams only. The rebar cover distance from the beam
bottom face.
Applies to concrete beams only. The rebar cover distance from the beam to
an adjacent element faces.
on page 480.
Beam Properties | 805
