Creating a 3D Beam System

You can create non-planar beam systems in which the elevation of a beam is defined by its sketch lines.
3D beam system
Note that sketched beam lines
Can only define slope when they are created using the Pick Supports tool.
That have a beam as their support always define slope.
That have a wall as their support have a Defines slope property that you can edit. The default value is
true.
Finished cantilevered beam system
Creating a 3D Beam System | 819
