To change the level type in a section or elevation view
1 Select the level line in the drawing area.
2 In the Type Selector, select a different level type.

Editing Level Lines in an Elevation View

You can change level lines in the following ways:
Resize level lines. Select the level line, click on the blue sizing handles, and drag the cursor left or right.
Raise or lower levels. Select the level line, and click the dimension value associated with it. Enter a new
value for the dimension
Relabel the level. Select the level and click the label box. Enter a new label for the level.

Moving Levels

You can move level lines in the following ways:
Select a level line. A temporary dimension displays between that level line and any level lines immediately
above and below.
Selected level line shown in red with temporary dimensions above and below it
To move the selected level up or down, click the temporary dimension, type a new value, and press
ENTER.
Drag the selected level line up or down.
To move multiple level lines, select the desired number of level lines and move them up or down.

Offsetting a Level Line from Its Bubble

There may be times when you sketch a level line and want to offset its bubble from the rest of the level line.
1 Sketch a level line, or select an existing level line.
The end of the line near the bubble has drag controls.
Modifying Levels | 1043
