See Modifying a Title Block
2 Modify the revision schedule properties, as follows:
a In the Project Browser, under Views (all)
click Properties.
b In the Element Properties dialog, for Appearance, click Edit.
c On the Appearance tab of the Revision Properties dialog, for Height, select User defined.
d Click OK twice.
3 In the drawing area, select the revision schedule of the title block.
The status bar displays Schedule Graphics : Schedule Graphics : Revision Schedule.
The bottom of the revision schedule displays a blue dot. Grid lines display to indicate the amount
of space required for each row of revision information (assuming one line per revision row; in
a sheet, long values wrap to the next line). In this mode, these grid lines display regardless of
whether the revision schedule is set to display grid lines.
4 Drag the blue dot up or down until the revision schedule is the desired height.
The blue dot indicates the bottom boundary of the revision schedule. If a sheet in a project has
more revisions than can fit in this space, Revit Architecture omits the oldest revisions from the
schedule.
5 To save the title block, click File menu
click Save.
6 Load the title block into a project.
See Loading a Title Block into a Project

Building a Revision Schedule from the Top Down or Bottom Up

Revision schedules can display information in various ways. Some design firms use a top-down approach,
with column headings and revision rows starting at the top of the schedule. Other design firms use a
bottom-up approach, with column headings and revision rows starting at the bottom of the schedule. In
either case, the revision schedule sorts the rows using the settings specified on the Sorting/Grouping tab of
the Revision Properties dialog. (See
on page 985.
Save, specify a location and file name (if needed), and
on page 987.
Adding a Revision Schedule to a Custom Title Block
Schedules, right-click Revision Schedule, and
Revision Schedules on Title Blocks | 991
on page 988.)
