Name
Mark
Phasing
Phase Created
Phase Demolished
Other
Schedule as

Roofs

Roofs are components that define different types of roofs for the building design. Various types of roofs can
be made in Revit Architecture.

Adding a Roof

Roofs can be made from the building footprint, as extrusions, or from mass instances. For information on
adding a roof from a mass instance, see
through windows or doors.
With the Roof by Footprint method of creating a roof, you specify the footprint or outline of the roof in a
plan view. You then define the slopes of the roof by identifying lines in the footprint that are edges of
sloping roof planes.
606 | Chapter 11 Working with Architectural Components
Description
A label applied to a wall. Usually a numeric value. This value must be unique for
each wall in a project. Revit Architecture warns you if the number is already used
but allows you to continue using it. You can see the warning using the Review
Warnings command. See Reviewing Warning Messages
The phase when the wall was created.
The phase when the wall was demolished.
Indicates whether the wall panel should schedule as a curtain panel or a wall.
Creating Roofs from Mass Instances
on page 1334.
on page 551. A roof cannot cut
