Perimeter Analysis Example

In a sample scenario, you have designed masses to explore a conceptual design for a building. (See Examples
of Conceptual Design Analysis on page 529.) The design contains many angles, and it may be too expensive
to build. You want to produce rough cost estimates, based on its linear dimensions, to check construction
costs for the project.
Creating a Perimeter Analysis Schedule
Use the following procedure to create a schedule for analyzing the perimeter of masses in a conceptual
design, based on the scenario described in Perimeter Analysis Example on page 536. Specific steps may vary
depending on the information that you want to show in the schedule.
To create a perimeter analysis schedule
1 Create mass floors.
See Creating Mass Floors on page 525.
