Applying a Color Scheme

1 In the Project Browser, right-click the floor plan view or section view to apply a color scheme
2 In the Element Properties dialog, click in the Color Scheme cell.
3 In the Edit Color Scheme dialog, under Schemes, select a color scheme from the list.
4 Click OK.
5 For Color Scheme Location, select one of the following values:
6 Click OK.
Related topic
Adding a Color Scheme Legend

Using a Color Scheme in a Section View

In addition to using a color scheme for a floor plan view, you can also use a color scheme to color and apply
fill patterns to rooms or areas in a section view. See
960 | Chapter 14 Rooms and Areas
to, and select Properties.
For information on creating a new color scheme, see
Background: Applies the color scheme to the background of the view only. For example, in
a floor plan view, it applies the color scheme to the floor only. In a section view, it applies
the color scheme to the background walls or surfaces only. The color scheme is not applied
to foreground elements in the view.
Foreground: Applies the color scheme to all model elements in the view.
on page 963
Creating a Color Scheme
Applying a Color Scheme
on page 958.
on page 960.
