Room Tag Properties

Use room tag properties to control the appearance and behavior of room tags.
Related topic
Room Properties on page 939
Modifying Room Tag Properties
1 In a plan or section view, select a room tag, and click
2 In the Element Properties dialog, edit room tag instance parameters.
See Room Tag Instance Properties
3 To edit room tag type parameters, click Edit/New.
See Room Tag Type Properties
4 Click OK.
Room Tag Type Properties
Name
Graphics
Show Volume
Show Room Number
Show Area
Leader Arrowhead
Room Tag Instance Properties
Name
Graphics
Leader Line
Orientation
on page 925.
on page 925.
Description
Displays the room's computed volume in the tag. If Not Computed displays, turn
on volume computation. See
Displays the room's assigned number in the tag.
Displays the room's computed area in the tag.
Specifies the shape of the arrowhead on the leader line.
Description
Turns on/off the leader line.
Specifies the orientation of the room tag: horizontal, vertical, or model. See
Orientation on page 922.
.
Enabling Volume Computations on page 929.
Tag
Room Tags | 925
