Creating a Drawing List

1 In a project, click View menu
2 On the Fields tab of the Drawing List Properties dialog, select the fields to include in the drawing
3 (Optional) To create user-defined fields, click Add Parameter.
4 Specify the remaining schedule properties using the Filter, Sorting/Grouping, Formatting, and
5 Click OK.
The resulting drawing list displays in the drawing area. In the Project Browser, it displays under
Schedules/Quantities.

Omitting Sheets from a Drawing List

You can omit sheets from the
drawing list.
To omit a sheet from a drawing list
1 In the Project Browser, right-click the name of the sheet to omit, and click Properties.
2 On the Element Properties dialog, clear Appears In Drawing List.
3 Click OK.
Revit Architecture updates the drawing list to exclude the sheet.

Adding a Drawing List to a Sheet

To add a drawing list to a sheet, use the procedure for adding a schedule to a sheet. See
to a Sheet on page 1002.
When you add a drawing list to a sheet, you can perform the same functions as for schedules on sheets,
including the following:
Formatting the drawing list
Splitting the drawing list
1006 | Chapter 15 Preparing Construction Documents
list.
See Selecting Fields for a Schedule
For further instructions, see
Appearance tabs. See Specifying Schedule Properties
drawing
This option is selected for all sheets by default.
New Drawing List.
on page 128.
Custom Parameters on page 440.
list. For example, you may not want the cover sheet to display in the
on page 128.
Adding a Schedule
